5: Verification test record forms Series 2260B Programmable Power Supplies
Verification and Adjustment Manual
5-4 077104802 / November 2016
80 Volt verification test record
Print this page and record your verification results that can be used for reference in the future. Make
sure to keep this record with your power supply.
Constant voltage tests:
Voltage programming
and measurement
Model Minimum
specifications
Results Maximum specifications
Rated voltage out All 79.91 V 80.090 V
Measurement accuracy All 79.9 V 80.1 V
CV load regulation Model Minimum
specifications
Results Maximum specifications
CV line regulation Model Minimum
specifications
Results Maximum specifications
CV ripple and noise Model Minimum
specifications
Results Maximum specifications
Peak-to-peak 80-13 N/A 60 mV
80-27 N/A 80 mV
80-40 N/A 100 mV
RMS 80-13 N/A 7 mV
80-27 N/A 11 mV
80-40 N/A 14 mV
