10: Adjustment code glossary Series 2260B Programmable Power Supplies
Verification and Adjustment Manual
10-2 077104802 / November 2016
Adjustment codes
Voltage display Current display Description
Power applied; Function key lights up
Password entered; instrument ready for adjustment
Enter constant voltage adjustment mode
Standby to execute external voltage adjustment
Output button illuminates and CV is displayed
Standby to execute external current adjustment
Output button illuminates and CC is displayed
Exit external current adjustment
Enter voltage adjustment mode
Standby adjustment offset voltage value
Adjustment offset voltage value
Standby adjustment half-scale voltage value
Adjustment full-scale voltage value
Standby adjustment full-scale voltage value
Adjustment full-scale voltage value
Enter current adjustment mode
Standby adjustment half-scale current value
Adjustment offset current value
Standby adjustment half-scale current value
Adjustment half-scale current value
Adjustment full-scale current value
Indicates adjustment results saved
The "x" in the previous table indicates that the value is not fixed.
