5: Verification test record forms Series 2260B Programmable Power Supplies
Verification and Adjustment Manual
5-6 077104802 / November 2016
250 Volt verification record
Print this page and record your verification results that can be used for reference in the future. Make
sure to keep this record with your power supply.
Model

2260B-250-4

2260B-250-9

2260B-250-13
Serial number:
Verified by
Name:
Company/contact:
Year:
Month:
Day:
Environment
Temperature:
Humidity:
Constant voltage tests:
Voltage programming
and measurement
Model Minimum
specifications
Results Maximum specifications
Minimum voltage out
All
-200 mV
+200 mV
Measurement accuracy
All
-200 mV
+200 mV
Rated voltage out All 249.47 V 250.53 V
Measurement accuracy All 249.47 V 250.53 V
CV load regulation Model Minimum
specifications
Results Maximum specifications
All
-130 mV
+130 mV
CV line regulation Model Minimum
specifications
Results Maximum specifications
All
-128 mV
+128 mV
CV ripple and noise Model Minimum
specifications
Results Maximum specifications
Peak-to-peak 250-4 N/A 80 mV
250-9 N/A 100 mV
250-13 N/A 120 mV
RMS 250-4 N/A 15 mV
250-9 N/A 15 mV
250-13 N/A 15 mV
