5: Verification test record forms Series 2260B Programmable Power Supplies Verification and Adjustment Manua
l
5-8 077104802 / November 2016
800 Volt verification record
Print this page and record your verification results that can be used for reference in the future. Make
sure to keep this record with your power supply.
Model

2260B-800-1

2260B-800-2

2260B-800-4
Serial number:
Verified by
Name:
Company/contact:
Year:
Month:
Day:
Environment
Temperature:
Humidity:
Constant voltage tests:
Voltage programming
and measurement
Model Minimum
specifications
Results Maximum specifications
Minimum voltage out
All
-400 mV
+400 mV
Measurement accuracy
All
-400 mV
+400 mV
Rated voltage out All 798.8 V 801.2 V
Measurement accuracy All 798.8 V 801.2 V
CV load regulation Model Minimum
specifications
Results Maximum specifications
All
-405 mV
+405 mV
CV line regulation Model Minimum
specifications
Results Maximum specifications
All
-403 mV
+403 mV
CV ripple and noise Model Minimum
specifications
Results Maximum specifications
Peak-to-peak 800-1 N/A 150 mV
800-2 N/A 200 mV
800-4 N/A 200 mV
RMS 800-1 N/A 30 mV
800-2 N/A 30 mV
800-4 N/A 30 mV
