Kenmore 600 Series User Manual

21
2
Right Side Shelf Assembly
□ Hang the Right Side Shelf onto brackets on right side of firebox. Make sure the Right Side front panel is in align
with the control panel.
□ Attach Right Side Shelf to firebox from inside with 2pcs M6x13 screws as shown (1).
□ Attach Right Side Shelf to firebox from outside with 3pcs M6x13 screws and 1pc M4x12 screw as shown (2) (3).
N direction
(Magnify）
A
B
A
A
A
A
M
M direction
(Magnify）
(1)
(2)
(3)
M6x13 Screws
Qty:5pcs
M4x12 Screws
Qty:1pc
A
B
