Before Setting Surface Burner Controls
Locations of the Gas Surface Burners
Your range is equipped with gas surface burners with
dierent BTU ratings. The ability to heat food quicker and in
larger volumes increases as the burner size increases.
The small burner is best used for simmering
delicate sauces, etc. This burner is located at the right rear
burner position on the cooktop.
The burner can be used for most surface
cooking needs. The standard burners are located at the left
front and center positions on the cooktop.
The burner is best used for bringing large quantities
of liquid rapidly up to temperature or when preparing larger
quantities of food. The POWER burners are located at the
right front and left rear burner positions on the cooktop.
Regardless of size, always select cookware that is suitable
for the amount and type of food being prepared. Select a
burner and ame size appropriate to the pan. Never allow
ames to extend beyond the outer edge of the pan.
burner grates
It is very important to make sure that all of the Surface
Burner Caps and Surface Burner Grates are installed
correctly and at the correct locations.
1. Remove all packing material from cooktop area.
2. Discard all packing material (if applicable).
3. Position the burner caps in the correct position.
4. Unpack Burner Grates and position on the cooktop.
Always keep the Burner Caps in place whenever
the surface burners are in use.
Burner Cap
Fixed Burner Head
Gas Opening
