3.
Reconnect the new duct[11 in(28cm)] to the
blower housing, and attach the duct to the base.
2.
Detach and remove the bottom, left or right side
knockout as desired.
4.
Pre-assemble 4" elbow with 4" duct.
Wrap duct tape around joint.
5.
Insert duct assembly, elbow first, through the side
opening and connect the elbow to the dryer
internal duct.
When you disassemble and install ventilation, be
sure to take gloves and careful exhaust edge.
Failure to do so can cause serious injury.
