Kenmore 796.98852800 User Manual

32
1.
Remove the filter.
2.
Remove 3 screws.
3.
Pull the grill.
4.
Disconnect electro sensor.
FILTER ASSEMBLY
1.
Open the top plate.
2.
Remove the Cover Cabinet and Tub Drum [Front].
3.
Remove the Drum assembly.
4.
Remove 2 screws and cover(Air guide).
5.
Remove the bolt and washer.
6.
Pull the fan.
7.
Disconnect the motor clamp and motor.
BLOWER HOUSING
1.
Open the top plate.
2.
Remove the Cover Cabinet and Tub Drum [Front].
3.
Remove the Drum assembly.
4.
Remove 7 screws.
5.
Pull the Tub Drum [Rear] towards the front.
BACK COVER
