- 19 -
BELT CHANGING AND BRUSHROLL CLEANING
3. Grasp cover by rear and pull up to
remove it from base.
4. Lift brushroll assembly out and remove
worn belt.
5. Check and clean end cap areas.
See picture on page 20 for complete
brushroll assembly.
Always follow all safety precautions when performing maintenance to the PowerMate
®
.
WARNING
Electrical Shock Or Personal Injury Hazard
Always turn off and unplug vacuum
cleaner
before performing maintenance
to the vacuum cleaner
. Failure to do so
could result in electrical shock or personal
injury from vacuum cleaner suddenly
starting.
POWERMATE
®
CARE
BELT CHANGING AND BRUSHROLL
CLEANING
1. Press handle release pedal and lower the
swivel. Turn PowerMate
®
upside down and
remove the four (4) screws securing base
to PowerMate
®
cover.
2. Turn PowerMate
®
right side up. Loosen
the rear and side latches. (A flat blade
screwdriver may be required.)
Brushroll
To Next Page
