DM-5090 (En)
15
Operation of remote control unit
1
Remove the cover. Insert batteries.
23
Close the cover.
÷ Insert two R6 (“AA”-size) batteries following
the polarity indications.
To switch the power of the unit ON, plug the power cord into
a wall outlet, press the POWER key of the main unit to ON
and press the ON/STANDBY key of the remote control unit.
Once the power has been switched ON, press the desired
operation key.
Operation
1. The provided batteries are intended for use in operation checking, and their service life may be short.
2. When the remote controllable distance becomes short, replace both of the batteries with new ones.
3. If direct sunlight or the light of a high- frequency fluorescent lamp (inverter type, etc.) is incident to the remote sensor, malfunction may
occur. In such a case, change the installation position to avoid malfunction.
÷ When pressing more than one remote control keys successively, press
the keys securely by leaving an interval of 1 second or more between
pressing of keys.
Loading batteries
Reference operating range
Model: RC-M0702
Infrared ray system
Remote sensor
2
1
Notes
Notes
6m
30° 30°
