Kenwood DM-SE7 User Manual

21
PARTS LIST
DM-SE7/SE7(G)/SE9
L : Scandinavia K : USA P : Canada R : Mexico 7 : DM-SE7 8 : DM-SE7(G)
Y : PX(Far East, Hawaii) T : Europe E : Europe G : Germany 9 : DM-SE9
Y : AAFES(Europe) X : Australia M : Other Areas
indicates safety critical components.
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
Ref. No
Add-
ress
New
Parts
Description
Desti-
nation
Re-
marks
Parts No.
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
Ref. No
Add-
ress
New
Parts
Description
Desti-
nation
Re-
marks
Parts No.
L : Scandinavia K : USA P : Canada R : Mexico 7 : DM-SE7 8 : DM-SE7(G)
Y : PX(Far East, Hawaii) T : Europe E : Europe G : Germany 9 : DM-SE9
Y : AAFES(Europe) X : Australia M : Other Areas
indicates safety critical components.
627 1C E30-2628-05 CORD WITH CONNECTOR
628 1D,1E E35-1934-05 FLAT CABLE
629 1E ✽ E35-1935-05 FLAT CABLE
630 1D,1E ✽ E35-1936-05 FLAT CABLE
631 1E ✽ E35-1937-05 FLAT CABLE
641 2D G11-2325-04 CUSHION M9E9T9
641 2D G11-2342-04 CUSHION M7E7T7
641 2D G11-2342-04 CUSHION T8K7
- H10-7359-02 POLYSTYRENE FOAMED FIXTURE M7E7T7
- H10-7359-02 POLYSTYRENE FOAMED FIXTURE T8K7
- H10-7360-02 POLYSTYRENE FOAMED FIXTURE M7E7T7
- H10-7360-02 POLYSTYRENE FOAMED FIXTURE T8K7
- H10-7361-02 POLYSTYRENE FOAMED FIXTURE M9E9T9
- H10-7362-02 POLYSTYRENE FOAMED FIXTURE M9E9T9
- ✽ H12-2359-04 PACKING FIXTURE T7T9T8
- H25-1579-04 PROTECTION BAG E7E9K7
- H25-1581-04 PROTECTION BAG T7T9T8
- H25-1595-04 PROTECTION BAG
- ✽ H25-1620-04 PROTECTION BAG M7M9
- H50-2505-04 ITEM CARTON CASE M7E7K7
- H50-2506-04 ITEM CARTON CASE T7
- ✽ H50-2568-04 ITEM CARTON CASE M9E9
- H50-2569-04 ITEM CARTON CASE T9
- ✽ H50-2675-04 ITEM CARTON CASE T8
645 2E J02-0370-05 FOOT
647 1E J42-0083-05 POWER CORD BUSHING
- J61-0307-05 WIRE BAND
650 2C K29-6741-04 KNOB M9E9T9
650 2C K29-6744-04 KNOB M7E7T7
650 2C K29-6744-04 KNOB T8K7
651 1D K29-6743-03 KNOB M7E7T7
651 1D K29-6743-03 KNOB T8K7
651 2D K29-6748-03 KNOB M9E9T9
655 2E ✽ L07-2393-15 POWER TRANSFORMER E7T7E9
655 2E ✽ L07-2393-15 POWER TRANSFORMER T9T8
655 2E ✽ L07-2394-15 POWER TRANSFORMER M7M9
655 2E L07-2452-05 POWER TRANSFORMER K7
C1 C90-3209-05 ELECTRO 10UF 6.3WV
C2 CK73FF1C474Z CHIP C 0.47UF Z
C3 CK73FB1E104K CHIP C 0.10UF K
C4 CC73FCH1H101J CHIP C 100PF J
C5 C90-3244-05 ELECTRO 10UF 35WV
C6 CC73FSL1H102J CHIP C 1000PF J
C11 CE04KW1E222M ELECTRO 2200UF 25WV
C12 CK45FB1H102K CERAMIC 1000PF K
C13 CE04KW1A221M ELECTRO 220UF 10WV
C14 CE04KW1J220M ELECTRO 22UF 63WV
C15 CE04KW1V4R7M ELECTRO 4.7UF 35WV
C16 CC73FSL1H102J CHIP C 1000PF J
CN1 E40-8147-05 FLAT CABLE CONNECTOR
CN2 E40-4296-05 FLAT CABLE CONNECTOR
601 1D ✽ A01-3497-01 METALLIC CABINET M7E7T7
601 1D ✽ A01-3497-01 METALLIC CABINET T8K7
602 1C A09-0129-08 BATTERY COVER (RC-MSE9)
602 1C A09-0356-08 BATTERY COVER (RC-MSE7)
604 1D A22-1781-01 SUB PANEL M7E7T7
604 1D A22-1781-01 SUB PANEL T8K7
604 1D ✽ A22-1782-01 SUB PANEL M9E9T9
605 2D ✽ A29-0875-04 PANEL M7E7T7
605 2D ✽ A29-0875-04 PANEL T8K7
605 2D ✽ A29-0876-04 PANEL M9E9T9
606 1D A50-1305-02 SIDE PLATE M9E9T9
607 1C A60-1204-03 PANEL M7E7T7
607 1C A60-1204-03 PANEL T8
607 1C ✽ A60-1242-03 PANEL M9E9T9
608 2C ✽ A60-1206-03 PANEL K7M7E7
608 2C ✽ A60-1206-03 PANEL T7
608 2C ✽ A60-1288-03 PANEL T8
608 2C A60-1340-03 PANEL K7
609 1C ✽ A70-1153-05 REMOTE CONTROLLER ASSY M7E7T7
609 1C ✽ A70-1153-05 REMOTE CONTROLLER ASSY T8K7
609 1C ✽ A70-1169-05 REMOTE CONTROLLER ASSY M9E9T9
615 1C B07-2363-04 ESCUTCHEON M7E7T7
615 1C B07-2363-04 ESCUTCHEON T8K7
616 2D B07-2364-03 ESCUTCHEON M7E7T7
616 2D B07-2364-03 ESCUTCHEON T8K7
616 2D ✽ B07-2365-03 ESCUTCHEON M9E9T9
617 2C B10-2372-03 FRONT GLASS
618 2C B12-0318-04 INDICATOR
619 1C B19-1529-05 OPTICAL FIBER
- B46-0310-03 WARRANTY CARD E7T7E9
- B46-0310-03 WARRANTY CARD T9T8
- B46-0328-03 WARRANTY CARD K7
- ✽ B60-3319-00 INSTRUCTION MANUAL(ENGLISH) T7T8K7
- ✽ B60-3320-00 INSTRUCTION MANUAL(FRENCH) E7
- ✽ B60-3321-00 INSTRUCTION MANUAL(GERMAN) E7
- ✽ B60-3322-00 INSTRUCTION MANUAL(DUTCH) E7
- ✽ B60-3323-00 INSTRUCTION MANUAL(ITALIAN) E7
- ✽ B60-3324-00 INSTRUCTION MANUAL(SPANISH) E7
- ✽ B60-3414-00 INSTRUCTION MANUAL(TAIWANESE) M7
- ✽ B60-3546-00 INSTRUCTION MANUAL(ENGLISH) T9
- ✽ B60-3547-00 INSTRUCTION MANUAL(FRENCH) E9
- ✽ B60-3548-00 INSTRUCTION MANUAL(GERMAN) E9
- ✽ B60-3549-00 INSTRUCTION MANUAL(DUTCH) E9
- ✽ B60-3550-00 INSTRUCTION MANUAL(ITALIAN) E9
- ✽ B60-3551-00 INSTRUCTION MANUAL(SPANISH) E9
- ✽ B60-3553-00 INSTRUCTION MANUAL(TAIWANESE) M9
624 1C E03-0115-05 AC PLUG ADAPTER M7M9
625 1C E30-0615-05 AUDIO CORD
626 1E E30-2592-15 AC POWER CORD E9M7E7
626 1E E30-2592-15 AC POWER CORD M9
626 1E E30-2650-05 AC POWER CORD K7
626 1E E30-2721-05 AC POWER CORD T7T9T8
1 2
DM-SE7/SE7G/SE9
DISPLAY UNIT (X14-4660-00)
DM-SE9 2,COVER( 98.4.25 9:49 y[W 14
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299

Kenwood DM-SE7 Specifications

System

minidisc digital audio system laser	semiconductor laser
recording method	field modulation overwrite method
audio compression	ATRAC (Adaptive TRansform Acoustic Coding)

Digital Audio Performance

frequency response (playback mode)	8 Hz ~ 20 kHz, ± 1 dB
signal to noise ratio (playback mode)	more than 92 dB
dynamic range (playback mode)	more than 90 dB

General

power consumption	14 W
dimensions	W: 200 mm, H: 77 mm, D: 247 mm
weight (net)	2.1 kg
