Beware of condensation
When water vapor comes into contact with the surface of
cold material, water drops are produced. If condensation
occurs, correct operation may not be possible, or the unit
may not function correctly.
This is not a malfunction, however, and the unit should be
dried.
(To do this, turn the POWER switch ON and leave the unit
as it is for several hours.)
Be especially careful in the following conditions:
• When the unit is brought from a cold place to a warm place
and there is a large temperature difference.
• When a heater starts operating.
• When the unit is brought from an air-conditioned place to
a place of high temperature with high humidity.
• When there is a large difference between the internal
temperature of the unit and the ambient temperature, or in
conditions where condensation occurs easily.
DM-SE7/SE7(G)/SE9
2
CONTENTS / ACCESSORIES / CAUTIONS
CONTENTS / ACCESSORIES / CAUTIONS...............2
CIRCUIT DESCRIPTION.............................................3
PC BOARD ................................................................. 6
SCHEMATIC DIAGRAM ............................................. 9
EXPLODED VIEW .....................................................19
PARTS LIST...............................................................21
PARTS DESCRIPTIONS ...........................................27
SPECIFICATIONS .......................................Back cover
Audio cord
(E30-0615-05)
Accessories
Contents
Batteries (2)
Remote control unit
(A70-1153-05) : RC-MSE7
(A70-1169-05) : RC-MSE9
Battery cover (A09-0129-08 : RC-MSE9)
(A09-0356-08 : RC-MSE7)
System control cord
(E30-2628-05)
Optical fiber
(B19-1529-05)
AC plug adapter
(E03-0115-05)
Cautions
Note related to transprotaion and movement
Before transporting or moving this unit, carry out
the following operations.
1. With no disc loaded in the unit, press the "on /
standby" key to on.
• Check that no disc is present in the unit.
2. Wait a few seconds and verify that the display
shown appears.
3. Press the "on / standby" key to off (standby).
