Kenwood DMX9707S User Manual

Basic Operations
14
Source control screen
descriptions
There are some functions which can be
performed from most screens.
Indicators
1 2
3
Short-cut source icons
1
All sources icon
Displays the source selection screen. (P.12)
2
Secondary screen
• [
]/[ ] : The Secondary screen changes to
another one every time you touch it. You can
also change the Secondary screen by flicking
left or right on the screen.
• Indicators: Displays the current source
condition and so on.
– [ATT]: The attenuator is active.
– [DUAL]: The dual zone function is active.
– [MUTE]: The mute function is active.
– [LOUD]: The loudness control function is active.
• Short-cut source icons: The source changes to
the one you have set with a short-cut. For the
short-cut setting, refer to Customize Short-
cut source icons on HOME screen (P.13).
3
• Connected Bluetooth device information.
List screen
There are some common function keys in the
list screens of most sources.
Display the list screen
1
Touch [1].
 The list screen appears.
51
2 3 4
1
Displays the list type selection window.
2
Text scroll
Scrolls the displayed text.
3
etc.
Keys with various functions are displayed here.
•
: Plays all tracks in the folder containing
the current track.
•
: Jumps to the letter you entered
(alphabetical search).
•
: Moves to the upper hierarchy
level.
4
[ ]/[ ]/[ ]/[ ] Page scroll
You can change pages to display more items by
touching [
]/[ ].
• [
]/[ ] : Displays the top or bottom page.
5
Return
Returns to the previous screen.
