Controlling Audio
60
Controlling Audio
You can adjust various settings such as audio
balance or subwoofer level.
1
Press the [HOME]/[ ] button.
2
Touch [ ].
3
Touch [Audio].
See the following section for each
setting.
• Set up Speaker / X’over (P.61)
• Controlling EQ / SW Level (P.62)
• Set Position / DTA (P.63)
• Controlling FAD / BAL / Zone (P.65)
• Set Volume Offset (P.67)
• Set Sound Effect (P.67)
• Use Audio Memory (P.71)
NOTE
• When the iDatalink (commercially available)
is connected, the best audio settings are set
automatically.
Each parameter as follows are set. (DMX9720XDS
only)
– Speaker / X’over
– EQ / SW Level
– Position / DTA
– FAD / BAL / Zone
– Sound Effect
• To recall the settings automatically adjusted
by the iDatalink connection when the settings
are changed manually, touch [Audio SETUP
Clear] in the Audio Memory setting menu.
(DMX9720XDS only) (P.71)
3-way speaker system setup
Select the appropriate crossover network
mode for the speaker system used (2-way or
3-way speaker system).
# CAUTION
• Connecting 3-way speakers with the 2-way
mode selected can break the speakers.
1
Press the [HOME]/[ ] button.
HOME screen appears.
2
Touch [ ].
Source selection screen appears.
3
Touch [STANDBY].
4
Press [ ] button 1 followed by the
[HOME]/[ ] button 2 for 1 second at the
same time.
2 1
Speaker system select screen appears.
5
Select the crossover network mode.
A confirmation screen appears.
6
Touch [Ye s ].
!B5A-3356-00_20DDX_M_FP_En.indb 60 2020/08/04 8:15
