KDC-1016/115S
MICRO COMPUTER’S DESCRIPTION
Pin No.
Pin Name I/O Description Processing Operation
82 SEG9 O LCD segment output terminal
83 SEG8 O LCD segment output terminal
84 SEG7 O LCD segment output terminal
85 SEG6 O LCD segment output terminal
86 SEG5 O LCD segment output terminal
87 SEG4 O LCD segment output terminal
88 SEG3 O LCD segment output terminal
89 SEG2 O LCD segment output terminal
90 SEG1 O LCD segment output terminal
91 VCC - VDD connection terminal connected to BU 5V lines
92 VREF -
A/D converter reference voltage
connected to BU 5V lines
input terminal
93 AVSS - Ground connection terminal connected to GND
94 (NC) O Not used(N.C.)
95 COM3 O LCD common output terminal
96 COM2 O LCD common output terminal
97 COM1 O LCD common output terminal
98 VL3 I LCD power supply input terminal
99 VL2 I LCD power supply input terminal
100 C2 I Not used(N.C.)
TEST MODE
1. To enter test mode
While holding the "Track Down" key and preset "6" key, reset the unit.
All indication segments are ON at the beginning of test mode.
2. To release test mode
Simply reset the unit.
(NOTE) The test mode is not canceled by ACC OFF, power OFF, momentary power down.
3. CD receiver test mode specification
Pressing the "Track Up" key jumps between tracks in the following order.
No.9No.15 No.10No.11No.12No.13No.14 No.9 (Same as the beginning)
Pressing the "Track down" key jumps to the previous track to the being played.
Pressing the preset "1" key jumps to No.28 track.
4. Audio adjustment
The volume is set to the shown as 22 at KDC-115S.
The volume is set to the shown as 30 at KDC-1016.
Loudness is OFF.
The BASS / TREBLE and BALANCE / FADER controls can be set to the full boost / full cut and full front / full rear respectively by
pressing the "Track Up" / "Track Down" keys.
Sound coordination doesn't appear for the Audio mode feed.
5. The inspection function of LCD
When all indication segments are ON ,the segments can be set to the following order respectively by pressing the "Track Up" key
/ "Track Down" keys.
All indication segments⇔Odd segments(Common 1 part)⇔Even segments(Common 2 part)⇔Odd segments(Common 3
part)⇔All indication segments.
