KRC-16,191,265L/R,26,291
18
✽ New Parts
Parts without Part No. are not supplied.
E & Z : Europe
indicates safety critical components.
Les articles non mentionnes dans le Parts No.
ne sont pas fournis.
K : North America
Teile ohne Parts No. werden nicht geliefert.
M : Other Areas
Ref. No. Parts No. Ref. No. Parts No.
222 2F
✽
E29-1869-02 CONDUCTIVE RUBBER
DC1 1C E30-4790-05 DC CORD
201 1C A02-1486-13 PLASTIC CABINET ASSY
203 1F A22-2386-13 SUB PANEL ASSY F1 2D F52-0006-05 FUSE (MINI BLADE TYPE) (10A)
205 2F
✽
A46-1748-01 REAR COVER F1 2D F52-0011-05 FUSE (MINI BLADE TYPE) (10A)
206 1D A52-0756-02 TOP PLATE
207 1F A53-1638-13 CASSETTE LID 226 1F G01-2525-04 TORSION COIL SPRING
227 3F G01-2793-14 COMPRESSION SPRING
PA1 3E
✽
A64-2508-02 PANEL ASSY (KRC-265RG) M2 228 1F G01-2987-04 TORSION COIL SPRING
PA1 3E
✽
A64-2509-02 PANEL ASSY (KRC-265L) M3M4 229 1F G01-2988-04 EXTENSION SPRING
PA1 3E
✽
A64-2515-02 PANEL ASSY (KRC-291) EE1ZZ1 230 2F G01-2990-04 COMPRESSION SPRING
PA1 3E
✽
A64-2516-02 PANEL ASSY (KRC-26) E2E3Z4
PA1 3E
✽
A64-2516-02 PANEL ASSY (KRC-26) Z5 - H10-4685-12 POLYSTYRENE FOAMED FIXTURE
- H25-0329-04 PROTECTION BAG (280X450X0.03) M2M3M4
PA1 3E
✽
A64-2517-02 PANEL ASSY (KRC-191) E4E5Z2 - H25-0329-04 PROTECTION BAG (280X450X0.03) ZZ1Z2
PA1 3E
✽
A64-2517-02 PANEL ASSY (KRC-191) Z3 - H25-0329-04 PROTECTION BAG (280X450X0.03) Z3Z4Z5
PA1 3E
✽
A64-2518-02 PANEL ASSY (KRC-16) E6E7Z6 - H25-0329-04 PROTECTION BAG (280X450X0.03) Z6Z7
PA1 3E
✽
A64-2518-02 PANEL ASSY (KRC-16) Z7
- H25-0337-04 PROTECTION BAG (180X300X0.03)
211 3C B07-2124-02 ESCUTCHEON - H25-1111-04 PROTECTION BAG (280X450X0.03) EE1E2
- B46-0100-50 WARRANTY CARD EE1E2 - H25-1111-04 PROTECTION BAG (280X450X0.03) E3E4E5
- B46-0100-50 WARRANTY CARD E3E4E5 - H25-1111-04 PROTECTION BAG (280X450X0.03) E6E7
- B46-0100-50 WARRANTY CARD E6E7 -
✽
H54-2230-03 ITEM CARTON CASE (KRC-265RG) M2
- B46-0100-50 WARRANTY CARD M2M3M4
-
✽
H54-2231-03 ITEM CARTON CASE (KRC-265LA) M3
- B46-0182-14 ID CARD EE4 -
✽
H54-2232-03 ITEM CARTON CASE (KRC-291A) E
- B46-0606-04 ID CARD E1E2E3 -
✽
H54-2233-03 ITEM CARTON CASE (KRC-291G) E1
- B46-0606-04 ID CARD E5E6E7 -
✽
H54-2234-03 ITEM CARTON CASE (KRC-26A) E2
- B46-0606-04 ID CARD M2M3M4 -
✽
H54-2235-03 ITEM CARTON CASE (KRC-191A) E4
- B46-0606-04 ID CARD ZZ1Z2
-
✽
H54-2236-03 ITEM CARTON CASE (KRC-191G) E5
- B46-0606-04 ID CARD Z3Z4Z5 -
✽
H54-2237-03 ITEM CARTON CASE (KRC-16A) E6
- B46-0606-04 ID CARD Z6Z7 -
✽
H54-2241-03 ITEM CARTON CASE (KRC-291YA) Z
- B58-1365-04 CAUTION CARD -
✽
H54-2242-03 ITEM CARTON CASE (KRC-291YG) Z1
-
✽
B64-2104-00 INST. MANUAL (ENG,T-CHI) M2M3M4 -
✽
H54-2243-03 ITEM CARTON CASE (KRC-191YA) Z2
-
✽
B64-2105-00 INST. MANUAL (ARABIC) M2M3M4
-
✽
H54-2244-03 ITEM CARTON CASE (KRC-191YG) Z3
-
✽
B64-2106-00 INST. MANUAL (ENGLISH) EE1E2 -
✽
H54-2387-03 ITEM CARTON CASE (KRC-265LG) M4
-
✽
B64-2106-00 INST. MANUAL (ENGLISH) E3E4E5 -
✽
H54-2388-03 ITEM CARTON CASE (KRC-26G) E3
-
✽
B64-2106-00 INST. MANUAL (ENGLISH) E6E7Z -
✽
H54-2389-03 ITEM CARTON CASE (KRC-16G) E7
-
✽
B64-2106-00 INST. MANUAL (ENGLISH) Z1Z2Z3 -
✽
H54-2473-03 ITEM CARTON CASE (KRC-26YA) Z4
-
✽
B64-2106-00 INST. MANAUL (ENGLISH) Z4Z5Z6
-
✽
H54-2474-03 ITEM CARTON CASE (KRC-26YG) Z5
-
✽
B64-2106-00 INST. MANUAL (ENGLISH) Z7 -
✽
H54-2475-03 ITEM CARTON CASE (KRC-16YA) Z6
-
✽
B64-2107-00 INST. MANUAL (FRE,GER,DUT) EE1E2 -
✽
H54-2476-03 ITEM CARTON CASE (KRC-16YG) Z7
-
✽
B64-2107-00 INST. MANUAL (FRE,GER,DUT) E3E4E5
-
✽
B64-2108-00 INST. MANUAL (ITA,SPA,POR) EE1E2 241 3E
✽
J19-5125-02 HOLDER
-
✽
B64-2108-00 INST. MANUAL (ITA,SPA,POR) E3E4E5 242 1C J21-9491-13 MOUNTING HARDWARE ASSY
244 3D J61-0307-05 WIRE BAND
-
✽
B64-2108-00 INST. MANUAL (ITA,SPA,POR) E6E7
-
✽
B64-2110-00 INST. MANUAL (RUS,POL,CZE) ZZ1Z2 246 3F K24-3545-04 KNOB (EJECT)
-
✽
B64-2110-00 INST. MANUAL (RUS,POL,CZE) Z3Z4Z5 247 3F K24-3546-04 KNOB (FF)
-
✽
B64-2110-00 INST. MANUAL (RUS,POL,CZE) Z6Z7 248 3F K24-3547-04 KNOB (REW)
-
✽
B64-2111-00 INST. MANUAL (HUN,CRO,SLO) ZZ1Z2 249 3E
✽
K24-3817-03 KNOB (SRC)
250 2E
✽
K24-3818-04 KNOB (RELEASE)
-
✽
B64-2111-00 INST. MANUAL (HUN,CRO,SLO) Z3Z4Z5
-
✽
B64-2111-00 INST. MANUAL (HUN,CRO,SLO) Z6Z7 251 3E
✽
K24-3819-04 KNOB (SEEK)
252 3E
✽
K25-1387-03 KNOB (AUTO,CLK)
216 1C D10-3031-04 LEVER 253 3E
✽
K25-1388-03 KNOB (ATT,PRE,RST)
217 1F D10-4446-03 LEVER 254 3E
✽
K25-1389-03 KNOB (FM/AM,AUD)
218 1F D10-4447-03 LEVER 255 3E
✽
K25-1390-03 KNOB (VOL)
219 1F D21-2329-04 SHAFT
ME1 2C D40-1136-05 CASSETTE MECHANISM ASSY 261 1C N99-1610-15 SCREW SET (1-SCREW) M2M3M4
262 1C
✽
N99-1719-05 SCREW SET (8-SCREW) M2M3M4
221 2D E29-1585-04 LEAD PLATE A 3D N30-3004-46 PAN HEAD MACHINE SCREW
E : KRC-291A E3 : KRC-26G E6 : KRC-16A M2 : KRC-265RG Z : KRC-291YA Z3 : KRC-191YG Z6 : KRC-16YA
E1 : KRC-291G E4 : KRC-191A E7 : KRC-16G M3 : KRC-265LA Z1 : KRC-291YG Z4 : KRC-26YA Z7 : KRC-16YG
E2 : KRC-26A E5 : KRC-191G M4 : KRC-265LG Z2 : KRC-191YA Z5 : KRC-26YG
A
d
d
N
e
w
Desti-
nation
Description
Desti-
nation
Description
A
d
d
N
e
w
KRC-16,191,265L/R,26,291
PARTS LIST
