Kenwood KRC-16A User Manual

KRC-16,191,265L/R,26,291
23
PARTS LIST
✽ New Parts
Parts without Part No. are not supplied.
E & Z : Europe
indicates safety critical components.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
K : North America
Teile ohne Parts No. werden nicht geliefert.
M : Other Areas
Ref. No. Parts No. Ref. No. Parts No.
Q352 KRA103S DIGITAL TRANSISTOR Q503 2SD601A TRANSISTOR E2E3E4
Q352 UN2112 DIGITAL TRANSISTOR Q503 2SD601A TRANSISTOR E5E6E7
Q353 DTC114YK DIGITAL TRANSISTOR Q503 2SD601A TRANSISTOR M2EE1
Q353 KRC107S DIGITAL TRANSISTOR Q503 2SD601A TRANSISTOR ZZ1Z2
Q353 UN2214 DIGITAL TRANSISTOR Q503 2SD601A TRANSISTOR Z3Z4Z5
Q450,451 DTC143TK DIGITAL TRANSISTOR Q503 2SD601A TRANSISTOR Z6Z7
Q450,451 UN2216 DIGITAL TRANSISTOR TH1 PTH9C42BD471Q POSITIVE RESISTOR
Q500 2SC2412K TRANSISTOR E2E3E4
Q500 2SC2412K TRANSISTOR E5E6E7 A1 2D X86-3322-70 TUNER UNIT
Q500 2SC2412K TRANSISTOR M2EE1
Q500 2SC2412K TRANSISTOR ZZ1Z2 276 2E B11-0991-04 OPTICAL DIFFUSER
Q500 2SC2412K TRANSISTOR Z3Z4Z5 277 2E B11-0992-04 REFLECTION SHEET
Q500 2SC2412K TRANSISTOR Z6Z7 278 2E B19-2019-03 LIGHTING BOARD
Q500 2SD601A TRANSISTOR E2E3E4 D1 -14 B30-1565-05 LED E3E5E7
Q500 2SD601A TRANSISTOR E5E6E7 D1 -14 B30-1565-05 LED M2M4E1
Q500 2SD601A TRANSISTOR M2EE1 D1 -14 B30-1565-05 LED Z1Z3Z5
Q500 2SD601A TRANSISTOR ZZ1Z2 D1 -14 B30-1565-05 LED Z7
Q500 2SD601A TRANSISTOR Z3Z4Z5 D1 -14 B30-1566-05 LED (RED) E4E6Z
Q500 2SD601A TRANSISTOR Z6Z7 D1 -14 B30-1566-05 LED (RED) M3EE2
Q501 DTC114TK DIGITAL TRANSISTOR E2E3E4 D1 -14 B30-1566-05 LED (RED) Z2Z4Z6
Q501 DTC114TK DIGITAL TRANSISTOR E5E6E7 D15 B30-1511-05 LED (RED) E4E6Z
Q501 DTC114TK DIGITAL TRANSISTOR M2EE1 D15 B30-1511-05 LED (RED) M3EE2
Q501 DTC114TK DIGITAL TRANSISTOR ZZ1Z2 D15 B30-1511-05 LED (RED) Z2Z4Z6
Q501 DTC114TK DIGITAL TRANSISTOR Z3Z4Z5 D15 B30-2025-05 LED E3E5E7
Q501 DTC114TK DIGITAL TRANSISTOR Z6Z7 D15 B30-2025-05 LED M2M4E1
Q501 UN2215 DIGITAL TRANSISTOR E2E3E4 D15 B30-2025-05 LED Z1Z3Z5
Q501 UN2215 DIGITAL TRANSISTOR E5E6E7 D15 B30-2025-05 LED Z7
Q501 UN2215 DIGITAL TRANSISTOR M2EE1 ED1 2E B38-1037-05 LIQUID CRYSTAL E3E5E7
Q501 UN2215 DIGITAL TRANSISTOR ZZ1Z2 ED1 2E B38-1037-05 LIQUID CRYSTAL M2M4E1
Q501 UN2215 DIGITAL TRANSISTOR Z3Z4Z5 ED1 2E B38-1037-05 LIQUID CRYSTAL Z1Z3Z5
Q501 UN2215 DIGITAL TRANSISTOR Z6Z7 ED1 2E B38-1037-05 LIQUID CRYSTAL Z7
Q502 DTA124EK DIGITAL TRANSISTOR E2E3E4 ED1 2E
✽
B38-1099-05 LIQUID CRYSTAL E4E6Z
Q502 DTA124EK DIGITAL TRANSISTOR E5E6E7 ED1 2E
✽
B38-1099-05 LIQUID CRYSTAL M3EE2
Q502 DTA124EK DIGITAL TRANSISTOR M2EE1 ED1 2E
✽
B38-1099-05 LIQUID CRYSTAL Z2Z4Z6
Q502 DTA124EK DIGITAL TRANSISTOR ZZ1Z2 PL1 ,2 B30-1485-05 LAMP (5.5V 0.125A)
Q502 DTA124EK DIGITAL TRANSISTOR Z3Z4Z5 C1 CK73GB1H102K CHIP C 1000PF K
Q502 DTA124EK DIGITAL TRANSISTOR Z6Z7 C2 ,3 CK73GB1E473K CHIP C 0.047UF K
Q502 KRA103S DIGITAL TRANSISTOR E2E3E4 C2 ,3 CK73GB1H473K CHIP C 0.047UF K
Q502 KRA103S DIGITAL TRANSISTOR E5E6E7 C4 CK73GB1H103K CHIP C 0.010UF K
Q502 KRA103S DIGITAL TRANSISTOR M2EE1
279 2E E29-1600-04 CONDUCTIVE RUBBER
Q502 KRA103S DIGITAL TRANSISTOR ZZ1Z2 J1 E59-0831-05 RECTANGULAR PLUG
Q502 KRA103S DIGITAL TRANSISTOR Z3Z4Z5
Q502 KRA103S DIGITAL TRANSISTOR Z6Z7 R2
✽
RK73GB2A102J CHIP R 1.0K J 1/10W
Q502 UN2112 DIGITAL TRANSISTOR E2E3E4 R3 -6
✽
RK73GB2A101J CHIP R 100 J 1/10W
Q502 UN2112 DIGITAL TRANSISTOR E5E6E7 R7
✽
RK73GB2A563J CHIP R 56K J 1/10W
R8
✽
RK73GB2A102J CHIP R 1.0K J 1/10W
Q502 UN2112 DIGITAL TRANSISTOR M2EE1 R9
✽
RK73GB2A473J CHIP R 47K J 1/10W
Q502 UN2112 DIGITAL TRANSISTOR ZZ1Z2
Q502 UN2112 DIGITAL TRANSISTOR Z3Z4Z5 R10
✽
RK73EB2E331J CHIP R 330 J 1/4W
Q502 UN2112 DIGITAL TRANSISTOR Z6Z7 R11
✽
RK73EB2E471J CHIP R 470 J 1/4W
Q503 2SC2412K TRANSISTOR E2E3E4 R12 ,13
✽
RK73EB2E331J CHIP R 330 J 1/4W
R14 ,15
✽
RK73EB2E471J CHIP R 470 J 1/4W
Q503 2SC2412K TRANSISTOR E5E6E7 R17 ,18
✽
RK73EB2E130J CHIP R 13 J 1/4W
Q503 2SC2412K TRANSISTOR M2EE1
Q503 2SC2412K TRANSISTOR ZZ1Z2 R21
✽
RK73GB2A4R7J CHIP R 4.7 J 1/10W
Q503 2SC2412K TRANSISTOR Z3Z4Z5
Q503 2SC2412K TRANSISTOR Z6Z7 D17 MA3062-M ZENER DIODE
E : KRC-291A E3 : KRC-26G E6 : KRC-16A M2 : KRC-265RG Z : KRC-291YA Z3 : KRC-191YG Z6 : KRC-16YA
E1 : KRC-291G E4 : KRC-191A E7 : KRC-16G M3 : KRC-265LA Z1 : KRC-291YG Z4 : KRC-26YA Z7 : KRC-16YG
E2 : KRC-26A E5 : KRC-191G M4 : KRC-265LG Z2 : KRC-191YA Z5 : KRC-26YG
N
e
w
Desti-
nation
Description Description
A
d
d
N
e
w
Desti-
nation
A
d
d
SWITCH UNIT (X16-151x-xx)
(X14-687x-xx)
