Kenwood KRF-V5200D Service Manual

PARTS LIST
Indicates safety critical components.
Ref. No.
L:
Scandinavia
K:
USA
P:
Canada
R:
Mexico
C:
China
I:
Malaysia
Y:
PX(Far East,Hawaii)
T:
England
E:
Europe
G:
Germany
V:
China(Shaghai)
Y:
AAFES(Europe)
X:
Australia
Q:
Russia
H:
Korea
M:
Other Areas
✽
New parts
Parts without
Parts No.
are not supplied.
Les articles non mentionnes dans le
Parts No.
ne sont pas fournis.
Teile ohne
Parts No.
werden nicht geliefert.
KRF-V5200D
30
Add-
ress
Parts No.
New
Parts
Description
Desti-
nation
Re-
marks
Ref. No.
Add-
ress
Parts No.
New
Parts
Description
Desti-
nation
Re-
marks
✽
New parts
Parts without
Parts No.
are not supplied.
Les articles non mentionnes dans le
Parts No.
ne sont pas fournis.
Teile ohne
Parts No.
werden nicht geliefert.
Indicates safety critical components.
L:
Scandinavia
K:
USA
P:
Canada
R:
Mexico
C:
China
I:
Malaysia
Y:
PX(Far East,Hawaii)
T:
England
E:
Europe
G:
Germany
V:
China(Shaghai)
Y:
AAFES(Europe)
X:
Australia
Q:
Russia
H:
Korea
M:
Other Areas
601 1A
✽
A01-3976-01 METALLIC CABINET, SILVER S
601 1A
✽
A01-3977-01 METALLIC CABINET, #3976BLAC B
603 2B
✽
A60-2508-01 PANEL, SILVER S
603 2B
✽
A60-2509-01 PANEL, BLACK B
604 1A
✽
A70-1719-05 REMOTE CONTROL ASSY, RC-R0517
-
✽
B60-5676-00 INSTRUCTION MANUAL (EN)
-
✽
B60-5677-00 INSTRUCTION MANUAL (5-LAN) E
610 2A
✽
B07-2745-01 ESCUTCHEON, SILVER S
610 2A
✽
B07-2746-01 ESCUTCHEON, #2746BLAC B
611 2A
✽
B07-2747-03 ESCUTCHEON, RING-S S
611 2A
✽
B07-2748-03 ESCUTCHEON, #2747BLAC B
612 2A
✽
B10-5621-02 FRONT GLASS, DISPLAY
613 2A
✽
B10-5623-03 FRONT GLASS, SELECTOR
614 2A
✽
B11-1634-04 COLOR FILTER, PURE-AUDI
615 2A
✽
B12-1408-04 INDICATOR, POWER
616 2A
✽
B12-1409-04 INDICATOR, SELECTOR
617 2A B43-0336-04 BADGE 620 1C
✽
E30-7330-05+ AC POWER CORD, AS ROUND PLUG X
620 1C E30-7368-05 AC POWER CORD, EN 2.5A E 621 1C
✽
E35-3943-05 FLAT CABLE, TUNER
622 1C,2C
✽
E35-3948-05 FLAT CABLE, 29PX09-X0
623 1B,2B
✽
E35-3953-05 FLAT CABLE, 27PX14-X0
624 1C
✽
F07-2037-02 COVER, FAN
FAN 1B
✽
F09-0192-05 FAN
- J61-0307-05 WIRE BAND 630 2C J02-1464-03 FOOT 631 1B,2C J19-3751-04 UNIT HOLDER 632 1B
✽
J19-6471-02 HOLDER, FAN
635 1C J42-0349-05 POWER CORD BUSHING 640 2A
✽
K29-8585-04 KNOB, JOG-S S
640 2A
✽
K29-8586-04 KNOB, #8586BLAC B
641 2A
✽
K29-8587-03 KNOB, VOL-S S
641 2A
✽
K29-8588-03 KNOB, #8587BLAC B
642 2A,2B
✽
K29-8589-02 KNOB, TACT-S S
642 2A,2B
✽
K29-8590-02 KNOB, #8589BLAC B
643 2A
✽
K29-8591-03 KNOB, POWER S
643 2A
✽
K29-8592-03 KNOB, #8591BLAC B
650 2B
✽
L07-3353-05 POWER TRANSFORMER, 230V, E E
650 2B
✽
L07-3354-05 POWER TRANSFORMER, 240V, X X
D
N82-2608-48 BINDING HEAD TAPTITE SCREW
F N89-3008-48 BINDING HEAD TAPTITE SCREW K N89-3018-48 BINDING HEAD TAPTITE SCREW 660 1A T90-0877-05 LEAD WIRE ANTENNA 661 1A T90-0893-05 LOOP ANTENNA 665 1C W02-4609-05 TUNER ASSY C11,12 CD04BJ1H100M ELECTRO 10UF 50WV C13,14 CC73GCH1H222J CHIP C 2200PF J C15,16 CC73GCH1H182J CHIP C 1800PF J C17,18 CC73GCH1H100D CHIP C 10PF D
C19 CC73GCH1H470J CHIP C 47PF J C20 CC73GCH1H101J CHIP C 100PF J C21 CK73GB1H472K CHIP C 4700PF K C31,32 CD04BJ1H100M ELECTRO 10UF 50WV C33,34 CC73GCH1H821J CHIP C 820PF J C35,36 CC73GCH1H222J CHIP C 2200PF J C37,38 CC73GCH1H100D CHIP C 10PF D C51,52 CD04BJ1H100M ELECTRO 10UF 50WV C53 CC73GCH1H222J CHIP C 2200PF J C54 CQ93FMG1H822J MYLAR 8200PF J C55 CC73GCH1H182J CHIP C 1800PF J C56 CQ93FMG1H822J MYLAR 8200PF J C57,58 CC73GCH1H100D CHIP C 10PF D C59 CC73GCH1H470J CHIP C 47PF J C60 CC73GCH1H330J CHIP C 33PF J C91,92 CC73GCH1H220J CHIP C 22PF J C93,94 CC73GCH1H100D CHIP C 10PF D C95 CK73GB1H102K CHIP C 1000PF K C96 CC73GCH1H101J CHIP C 100PF J C111 CD04BJ1H2R2M ELECTRO 2.2UF 50WV C112 CC73GCH1H471J CHIP C 470PF J C113 CC73GCH1H222J CHIP C 2200PF J C114 CD04BJ1E470M ELECTRO 47UF 25WV C115 CC73GCH1H220J CHIP C 22PF J C116,117 CC73GCH1H101J CHIP C 100PF J C118 CC73GCH1H182J CHIP C 1800PF J C128 CC73GCH1H102J CHIP C 1000PF J C153,154 CC73GCH1H100D CHIP C 10PF D C158 CC73GCH1H100D CHIP C 10PF D C161,162 CK73GB1E154K CHIP C 0.15UF K C163,164 CK73GB1H473K CHIP C 0.047UF K C165,166 CK73GB1H223K CHIP C 0.022UF K C171,172 CC73GCH1H101J CHIP C 100PF J C173,174 CC73GCH1H100D CHIP C 10PF D C175,176 CC73GCH1H330J CHIP C 33PF J C177 CC73GCH1H102J CHIP C 1000PF J C181,182 CC73GCH1H101J CHIP C 100PF J C183,184 CC73GCH1H100D CHIP C 10PF D C185,186 CC73GCH1H330J CHIP C 33PF J C191 CC73GCH1H101J CHIP C 100PF J C193 CC73GCH1H100D CHIP C 10PF D C195 CC73GCH1H330J CHIP C 33PF J C201-218 CD04BJ1H100M ELECTRO 10UF 50WV C219,220 CC73GCH1H101J CHIP C 100PF J C221-226 CD04BJ1H100M ELECTRO 10UF 50WV C231-236 CD04BJ1H100M ELECTRO 10UF 50WV C237 CC73GCH1H102J CHIP C 1000PF J C239 CC73GCH1H100D CHIP C 10PF D C241-244 CD04BJ1H100M ELECTRO 10UF 50WV C301,302 CC73GCH1H221J CHIP C 220PF J C303,304 CC73GCH1H101J CHIP C 100PF J C305,306 CC73GCH1H221J CHIP C 220PF J C307,308 CC73GCH1H101J CHIP C 100PF J C309 CK73GB1H102K CHIP C 1000PF K C311,312 CC73GCH1H221J CHIP C 220PF J
KRF-V5200D
SURROUND (X08-3482-70)
1 2
