Kenwood KRF-V5200D Service Manual

PARTS LIST
Indicates safety critical components.
Ref. No.
L:
Scandinavia
K:
USA
P:
Canada
R:
Mexico
C:
China
I:
Malaysia
Y:
PX(Far East,Hawaii)
T:
England
E:
Europe
G:
Germany
V:
China(Shaghai)
Y:
AAFES(Europe)
X:
Australia
Q:
Russia
H:
Korea
M:
Other Areas
✽
New parts
Parts without
Parts No.
are not supplied.
Les articles non mentionnes dans le
Parts No.
ne sont pas fournis.
Teile ohne
Parts No.
werden nicht geliefert.
KRF-V5200D
38
Add-
ress
Parts No.
New
Parts
Description
Desti-
nation
Re-
marks
R421,422 RK73GB2A2R2J CHIP R 2.2 J 1/10W R423 RK73GB2A472J CHIP R 4.7K J 1/10W R425,426 RK73GB2A472J CHIP R 4.7K J 1/10W R451 RK73GB2A000J CHIP R 0.0 J 1/10W R611,612 RK73GB2A2R2J CHIP R 2.2 J 1/10W R619 RK73GB2A102J CHIP R 1.0K J 1/10W R620-622 RK73GB2A101J CHIP R 100 J 1/10W R623,624 RK73GB2A750J CHIP R 75 J 1/10W R625,626 RK73GB2A104J CHIP R 100K J 1/10W R627-629 RK73GB2A750J CHIP R 75 J 1/10W R651-653 RK73GB2A102J CHIP R 1.0K J 1/10W R655 RK73GB2A000J CHIP R 0.0 J 1/10W R701-703 RK73GB2A102J CHIP R 1.0K J 1/10W X R704-713 RK73GB2A750J CHIP R 75 J 1/10W X R714 RK73GB2A104J CHIP R 100K J 1/10W X R715 RK73GB2A750J CHIP R 75 J 1/10W X R716 RK73GB2A104J CHIP R 100K J 1/10W X R717 RK73GB2A750J CHIP R 75 J 1/10W X R718 RK73GB2A104J CHIP R 100K J 1/10W X R721,722 RK73GB2A2R2J CHIP R 2.2 J 1/10W X K201 S76-0131-15 MAGNETIC RELAY S103-109 S70-0086-05 TACT SWITCH S111,112 S70-0086-05 TACT SWITCH S302 S70-0086-05 TACT SWITCH S101,102 T99-0666-05 ROTARY ENCODER, 12CLICK S301 T99-0664-05 ROTARY ENCODER, VOLUME D101 MTZJ6.2(B) ZENER DIODE D105 1SS133 DIODE D107 1SS133 DIODE D109 1SS133 DIODE D201,202 1SS133 DIODE D204-208 1SS133 DIODE D301-304 1SS133 DIODE D401 MTZJ3.3(B) ZENER DIODE ED101 11-MT-143GNK FLUORESCENT INDICATOR TUBE IC101 MN12510F MOS-IC IC321 BA4560RF ANALOGUE IC IC401 KIA7805API-P ANALOGUE IC IC402 KIA7905PI-P ANALOGUE IC IC602 NJM2595M-ZB ANALOGUE IC IC701 NJM2586AM-ZB ANALOGUE IC X Q101-106 2SC1740S(Q, R) TRANSISTOR Q111 DTC124EUA DIGITAL TRANSISTOR Q112-114 DTA143TUA DIGITAL TRANSISTOR Q201 2SC1740S(Q, R) TRANSISTOR Q401 2SA1576A(R, S) TRANSISTOR Q402 DTC124EUA DIGITAL TRANSISTOR Q403,404 2SA1576A(R, S) TRANSISTOR Q405 2SC4081(R, S) TRANSISTOR A101 W02-4600-05 ELECTRIC CIRCUIT MODULE, 38KHZ
HOW TO READ THE PARTS LIST
ABBREVIATION OF MODEL AND MASS PRODUCTION’S
DESTINATIONS
MODEL ABB.
Australia Europe
XE
KRF-V5200D B X1 E
KRF-V5200D-S S X2 E1
17
