Kenwood KRF-V8060D User Manual

10
EN
VIDEO 1 VIDEO 2 VIDEO 3
PLAY INPLAY INPLAY INREC OUT
OUT
VIDEO
IN
VIDEO
IN
VIDEO
DVD
IN
IN
VIDEO
MONITOR
OUT
VIDEO
S VIDEO
OUT
VIDEO
S VIDEO
IN
VIDEO
S VIDEO
IN
VIDEO
S VIDEO
IN
VIDEO
DVD
IN
MONITOR
OUT
S VIDEO
Connecting video components
IN
Video deck
Monitor TV
A video component with digital audio outputs should be connected to the VIDEO 2 or VIDEO 3 jacks.
Video
IN/OUT
IN
Video inputs and outputs
(Yellow RCA pin cords)
OUT
OUT
Audio inputs
and outputs
S Video jacks
Video inputs
(Yellow RCA pin cords)
About the S VIDEO
jacks
S VIDEO
Use the S VIDEO jacks to
make connections to
video components with
S VIDEO IN/OUT jacks.
•
If you use the S VIDEO
jacks to connect your video
playback components, be
sure to use the S VIDEO
jacks when connecting
your monitor and video
recording components.
VIDEO
IN
OUT
OUT
Audio
IN/OUT
Setting up the system
OUT
OUT
DVD player or LD player
DVD player or LD player
•VR6060/09-20/EN 3/11/02, 8:48 PM10
