CIRCUIT DESCRIPTON
START
" " KEY
TRAY OPEN IF THE ERROR OCCURS,
GO TO ERROR MODE
DISC SKIP
DISC SKIP
DISC SKIP
TRAY CLOSE
DISC X PLAY
DISC SKIP
DISC Y PLAY
DISC SKIP
DISC Z PLAY
4. Standard Specification of Stereo System Error Message Display Contents
Error Contents Display Notes
Output while Device Protection Operation 'PROTECT'
Due to over current detection or unit in protect circuit operation.
DSP Control Error 'ER-AP**'
10:DSP Control Error (general)
TAPE Mechanism Error 'ER-TA**'
00:Tape Mechanism Error
01:Initial Error
CD/VCD
Pick-Up Mechanism Error 'ER-CD**'
00:Pick-up Mechanism Error
01:PU-IN SW Detection NG
CD Changer Mechanism Error 'ER-CD**'
10:Changer Error
11:Initial Error
Tray Error 'ER-CD**'
20:Tray Error
Focus Not Match 'NO DISC'
Micon Communication Error 'ER-CD**'
30:System-VCD
31:Syatem-CD Servo
TUNER
PLL UnLock 'ER-TU**'
00:TUN Error
01:PLL Unlock
RDS Connection WEAK SIG Signal is too weak to receive.
3-3-4 CD Changer Aging Test Mode
