AM Loop Antenna(1)
(T90-0879-08)
“AA” size battery (UM/SUM-3,
R6, HP-7 or similar)(2)
Remote Control(1)
(A70-1531-08): MXM3M5
(A70-1537-08): ETE2
FM Antenna(1)
(T90-0883-08)
Use to adapt the plug on the
power cord to the shape of the
wall outlet.
(Accessory only for regions where
use is necessary.)
AC Plug Adaptor (1)
(E03-0115-05)
RXD-655/755
2
CONTENTS / ACCESSORIES
CONTENTS / ACCESSORIES .................................. 2
EXTERNAL VIEW .......................................................3
DISASSEMBLY FOR REPAIR....................................4
BLOCK DIAGRAM ......................................................9
CIRCUIT DESCRIPTION ..........................................10
ADJUSTMENT ..........................................................15
PC BOARD .............................................................. 16
SCHEMATIC DIAGRAM .......................................... 23
EXPLODED VIEW ....................................................31
PARTS LIST..............................................................33
SPECIFICATIONS ......................................Back cover
Contents
Accessories
CLASS 1
LASER PRODUCT
The marking this product has been
classified as Class 1. It means that there
is no danger of hazardous radiatio
outside the product.
SYSTEM MAIN UNIT DESTINATION SPEAKER
XD-655 RXD-655 ET LS-N50S
XD-655E RXD-655E E2 LS-N50S
XD-655-GR RXD-655-GR ET LS-N50S-GR
XD-655E-GR RXD-655E-GR E2 LS-N50S-GR
XD-655-H RXD-655-H E LS-N50S-H
XD-655E-H RXD-655E-H E2 LS-N50S-H
XD-655-H RXD-655M-H M LS-N50S-H
XD-655 RXD-655M MX LS-N50S
XD-655(M3) RXD-655L(M3) M3 LS-N50S(M3)
XD-655(M5) RXD-655L(M5) M5 LS-N50S(M3)
XD-755 RXD-755 ET LS-N70S
XD-755E RXD-755E E2 LS-N70S
XD-755 RXD-755M MX LS-N70S
XD-755(M3) RXD-755L(M3) M3 LS-N70S(M3)
XD-755(M5) RXD-755L(M5) M5 LS-N70S(M3)
XD-855 RXD-755 ET LS-N90S
XD-855E RXD-755E E2 LS-N90S
XD-855 RXD-755M MX LS-N90S
XD-855(M3) RXD-755L(M3) M3 LS-N90S(M3)
XD-855(M5) RXD-755L(M5) M5 LS-N90S(M3)
SYSTEM CONFIGURATION CAUTIONS
