RXD-655/755
3
EXTERNAL VIEW
ANTENNA
AM LOOP
FM
75
VIDEO
/AUX
++
--
L
R
RL
SPEAKERS
Pin jack
(E63-1219-08)
Pin jack(AM)
(E40-8933-08)
Cabinet(TOP)
(A02-3014-08)
Lock terminal board
(E70-0144-08)
AC power cord bushing
(J42-0338-08)
AC power cord *
(E30-)
FM Antenna
(E70-0145-08)
* Refer to parts list on page 33 .
