Kenwood TK-2312 Service Manual

TK-2312/2317
✽
New Parts.
indicates safety critical components.
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
19
Ref. No. Ad dress Parts No. Description
Desti-
nation
New
parts
Ref. No. Ad dress Parts No. Description
Desti-
nation
New
parts
PARTS LIST
L : Scandinavia K : USA P : Canada
Y : PX (Far East, Hawaii) T : England E : Eu rope
C : China X : Australia M : Oth er Areas
TK-2312/2317
TX-RX UNIT (X57-7880-20)
PARTS LIST
1 1A
✽
A02-4095-23 PLASTIC CABINET ASSY
3 2C,2E B09-0725-03 CAP ACCESSORY
4 1B B43-1622-04 BADGE (FRONT)
5 1B B43-1623-04 BADGE (REAR)
6 1E
✽
B62-2237-00 INSTRUCTION MANUAL ACCESSORY M
7 1C
✽
B62-2238-00 INSTRUCTION MANUAL ACCESSORY P1,K1,M1
9 1A D10-0649-03 LEVER
10 1A D21-0863-04 SHAFT (LEVER)
11 1A D32-0441-13 STOPPER (LEVER)
13 2A E04-0477-15 RF COAXIAL RECEPTACLE (SMA)
14 3A E23-1253-04 TERMINAL (GND)
15 2A E23-1254-04 TERMINAL (+VE)
16 1B E37-1165-15 PROCESSED LEAD WIRE (SP/RED)
17 1B
✽
E37-1514-05 PROCESSED LEAD WIRE (SP/BLK)
19 3A F20-3353-14 INSULATING SHEET (+VE)
21 2A G01-4542-04 COIL SPRING
22 2A G01-4543-14 COIL SPRING
23 2B G10-1330-04 FIBROUS SHEET (IC)
24 2A G11-4465-04 RUBBER SHEET (FET)
25 3A G13-2009-04 CUSHION (CHASSIS)
27 3A G13-2033-04 CUSHION (-VE)
28 3A G13-2034-14 CUSHION (CHASSIS)
29 2B G13-2038-34 CUSHION (X57)
30 2B G13-2088-04 CUSHION (IC820)
31 2A
✽
G13-2340-14 CUSHION (CF401,CF402)
34 2B
✽
G13-2346-04 CUSHION (X57)
35 3A G53-1604-03 PACKING (CHASSIS)
36 2A G53-1605-03 PACKING
37 2A G53-1802-04 PACKING (SMA)
39 2B
✽
G53-1845-03 PACKING (VOL/SEL)
40 1B
✽
G53-1846-03 PACKING (SPK)
41 1B
✽
G53-1847-03 PACKING (SP/MIC)
43 2D H12-4251-05 PACKING FIXTURE K1
44 3D H52-2300-13 ITEM CARTON CASE K1
46 2A J19-5463-03 HOLDER (+VE)
47 2A J19-5473-03 HOLDER ASSY (+VE)
48 2C,2E
✽
J19-5549-03 HOLDER (SP/MIC) ACCESSORY
49 2B
✽
J19-5545-14 HOLDER ASSY (SPK)
50 2C,1E J29-0734-05 BELT CLIP ACCESSORY
52 2A
✽
J82-0127-05 FPC
54 1B K29-9309-13 KNOB (VOL)
55 1A
✽
K29-9425-03 BUTTON KNOB (PTT)
56 1A
✽
K29-9426-03 BUTTON KNOB (SIDE1,2)
57 1B
✽
K29-9427-03 KNOB (SELECTOR)
58 1A
✽
K29-9463-02 KEY TOP (7KEY)
A 2A N14-0848-05 CIRCULAR NUT (SELECTOR)
B 2B N14-0849-05 CIRCULAR NUT (VOL)
C 2A N30-2604-48 PAN HEAD MACHINE SCREW (SMA)
D 3A N30-2606-48 PAN HEAD MACHINE SCREW
E 2B,3A N83-2005-48 PAN HEAD TAPTITE SCREW
60 2C,2E N99-2046-05 SCREW SET ACCESSORY
VR1 2A
✽
R31-0676-05 VARIABLE RESISTOR
62 1B T07-0787-05 SPEAKER
63 2D T90-1036-15 HELICAL ANTENNA ACCESSORY P1,K1,M1
64 1B
✽
T91-0672-05 MIC ELEMENT (WITH LEAD WIRE)
W1 2A
✽
W02-3748-05 ENCODER (SELECTOR)
66 1D W08-0988-05 CHARGER (KSC-35) ACCESSORY K1,M1
67 1D W08-0989-25 AC ADAPTER (KSC-35) ACCESSORY K1
68 1D W08-0992-05 AC ADAPTER (KSC-35) ACCESSORY M1
69 1D W08-1097-05 CHARGER (KSC-31) ACCESSORY P1
71 1D W08-1205-05 AC ADAPTER (KSC-31) ACCESSORY P1
101 2B
✽
B11-1876-03 ILLUMINATION GUIDE (LCD)
102 2B
✽
B11-1877-14 FILTER (LCD)
103 2B
✽
B38-0935-05 LCD
D801 B30-1790-05 LED (BLUE)
D804 B30-2314-05 LED (GREEN)
D805 B30-2315-05 LED (RED)
D818-821
✽
B30-2337-05 LED (YELLOW)
D824
✽
B30-2337-05 LED (YELLOW)
C1 CC73HCH1H101J CHIP C 100PF J
C3 CC73HCH1H100B CHIP C 10PF B
C4 CK73HB1H102K CHIP C 1000PF K
C5 CC73HCH1H101J CHIP C 100PF J
C7 CC73HCH1H100B CHIP C 10PF B
C8 CC73HCH1H101J CHIP C 100PF J
C9 CK73HB1E103K CHIP C 0.010UF K
C10 CC73HCH1H101J CHIP C 100PF J
C11 CK73HB1E103K CHIP C 0.010UF K
C12 CC73HCH1H101J CHIP C 100PF J
C14 CK73HB1A473K CHIP C 0.047UF K
C15 CK73HB1A224K CHIP C 0.22UF K
C16,17 CC73HCH1H101J CHIP C 100PF J
C18 CK73HB1E103K CHIP C 0.010UF K
C19 CC73HCH1H101J CHIP C 100PF J
C20 CK73HB1H471K CHIP C 470PF K
C21 CK73HB1E103K CHIP C 0.010UF K
C23 CS77CA1VR15M CHIP TNTL 0.15UF 35WV
C24 C92-0588-05 CHIP TNTL 1.5UF 16WV
C25 C92-0872-05 CHIP TNTL 0.22UF 10WV
C27 CK73HB1A224K CHIP C 0.22UF K
C28 CK73HB1H471K CHIP C 470PF K
C29,30 CC73HCH1H150J CHIP C 15PF J
C33 CC73HCH1H470J CHIP C 47PF J
C34 CK73HB1H471K CHIP C 470PF K
C35 CK73HB1E103K CHIP C 0.010UF K
C37,38 CK73HB1A104K CHIP C 0.10UF K
TK-2312/2317
TX-RX UNIT (X57-7880-20)
K1: TK-2312 K M1: TK-2312 M P1: TK-2312 P
M: TK-2317 M
