TK-2312/2317
3
SYSTEM SET-UP
REALIGNMENT
Choose the type of transceiver
Transceiver programming
Delivery
Merchandise received
Are you using the speaker microphone?
A personal computer, programming interface (KPG-22/22A),
and FPU (programming software) are required for programming.
(The frequency, TX power HI/LOW, and signaling data are
programmed for the transceiver.)
YES
NO
KMC-21, KMC-45 or KMC-48GPS
Speaker microphone
(Option)
Are you using the optional antenna?
YES
NO
KRA-22 or KRA-26
Optional antenna
TX/RX 136~174 5.0W TK-2312 K,M,P
Frequency range (MHz) RF power Type
TX/RX 136~174 5.0W TK-2317 M
1. Modes
User mode
Data programming mode
PC test mode
PC tuning mode
PC mode
Wireless clone mode
Firmware version information mode
Self-programming mode
Mode Function
User mode For normal use.
PC mode
Used for communication between the trans-
ceiver and PC.
Mode Function
Data programming
mode
Used to read and write frequency data and
other features to and from the transceiver.
PC test mode
Used to check the transceiver using the PC.
This feature is included in the FPU.
Wireless clone
mode
Used to transfer programming data from one
transceiver to another.
Firmware version
information mode
Used to confi rm the internal fi rmware ver-
sion.
Self-programming
mode
You can program the frequency signaling and
other function using only the transceiver.
2. How to Enter Each Mode
Mode Operation
User mode Power ON
PC mode Received commands from PC
Wireless clone mode [<B] + Power ON (Two seconds)
Firmware version
information mode
[Side1] + [Side2] + Power ON (Two
seconds)
Self-programming mode [S] + Power ON (Two seconds)
