TK-8302/8302H
4
Merchandise received
License and frequency allocated by FCC
Choose the type of transceiver
Transceiver programming
KCT-60
Connection cable
KCT-36
Extension cable
KES-5
External speaker
KCT-18
Ignition sense cable
KES-3
External speaker
See page 4.
A personal computer, programming interface (KPG-46/46A),
and FPU (programming software) are required for programming.
Frequency
range (MHz)
RF power
Type
400~470 25W TK-8302 M2
TK-8302H K2400~470 45W
(Option)
(Option)
(Option)
(Option)
(Option)
Delivery
See page 7.
See page 7. See page 7.
See page 6.
SYSTEM SET-UP
1. Modes
User mode
PC mode
PC programming mode
PC test mode
PC tuning mode
Clone mode
Mode Function
User mode For normal use.
PC mode
Used for communication between the trans-
ceiver and PC.
PC programming
mode
Used to read and write frequency data and
other features to and from the transceiver.
PC test mode
Used to check the transceiver using the PC.
This feature is included in the FPU.
PC tuning mode Used to tune the transceiver using the PC.
Clone mode
Used to transfer programming data from one
transceiver to another.
REALIGNMENT
2. How to Enter Each Mode
Mode Operation
User mode Power ON
PC mode Received commands from PC
Clone mode [
]+Power ON (Two seconds)
3. PC Mode
3-1. Preface
The transceiver is programmed using a personal com-
puter, a programming interface (KPG-46/46A, USB adapter
(KCT-53U)) and FPU (programming software).
The programming software can be used with a PC. Fig-
ure 1 shows the setup of a PC for programming.
3-2. Connection procedure
1. Connect the transceiver to the computer using the inter-
face cable and USB adapter (When the interface cable is
KPG-46A, the KCT-53U can be used.).
To Next Page
