TM-271A/271E
25
Item Condition
Test equipment
Terminal
Parts Method
Specifications/
Remarks
Measurement
Adjustment
ADJUSTMENT
If normal power is not obtained, please follow the
step below
Open the shielding cover (upper), and screw 3 locations
around ANT pin.
1. Switch off the transceiver.
Impedance of Final FET (Q504) and Drive FET (Q503) can
be measured easily using DVM Ω mode.
Normal condition – Gate : 20kΩ~50kΩ, Drain : 1MΩ~2MΩ
The above impedance values are rough estimations.
2. Switch on the transceiver. Check the voltage at F501 out-
put point.
The voltage is around 13.8V in receiving condition. The
voltage will be 12.6V~ in transmitting condition. If found
0V at this point then F501 is broken.
3. Remove R516.
4. Connect 50Ω load at the ANT location.
Transmit and check current drain at High power mode.
If the current drain is less than 1A, then Final FET is bro-
ken.
If the current drain is less than 5.0A, short the Drive FET
gate to ground, and check the current drain.
If the current drain is not 0.1A less than the original value,
then the Drive FET is broken.
5. Check input power level at Drive FET gate location.
Connect the wire to [RF] location.
Transmit and check for power to be within the range of
0.3W~0.6W.
If power found is less than 0.3W, check the circuit before
the Drive FET.
6. MAX 1) CH : TX low (Wide) Modulation analyzer ANT Encoder ± 4.0kHz (Wide) ±100Hz (Wide)
deviation CH : TX center (Wide/Narrow) or Linear detector MIC knob ± 2.0kHz (Narrow) ± 50Hz (Narrow)
CH : TX high (Wide) (LPF : 15kHz) According to the large +, –
2) AG : 1kHz/50mV Oscilloscope
3) Transmit AG
AF V.M
7. MIC 1) CH : TX center (Narrow) Check ±1.2~1.9kHz
sensitivity 2) AG : 1kHz/5.4mV (TM-271A) (Narrow)
AG : 1kHz/2.4mV (TM-271E)
3) Transmit
8. CTCSS 1) CH : TX low (Wide) Modulation analyzer Encoder ± 0.75kHz (Wide) ± 50Hz
fine CH : TX center (Wide/Narrow) or Linear detector knob ± 0.35kHz (Narrow)
deviation CH : TX high (Wide) (LPF : 3kHz)
2) Transmit Oscilloscope
9. DCS fine 1) CH : TX low (Wide) ±0.75kHz (Wide) ± 50Hz (Wide)
deviation CH : TX center (Wide/Narrow) ±0.35kHz (Narrow) ± 40Hz (Narrow)
CH : TX high (Wide)
2) Transmit
10. DTMF 1) CH : TX center (Wide/Narrow) ± 3.0kHz (Wide) ± 200Hz (Wide)
fine 2) Transmit ±1.5kHz (Narrow) ± 100Hz (Narrow)
deviation
Receiver Section
1.
Band pass
1) CH : RX low (Wide) SSG ANT Encoder Adjust to maximum SINAD. SINAD
tuning CH : RX center (Wide/Narrow) Oscilloscope EXT. SP knob : 12dB or higher
CH : RX high (Wide) AF V.M
2) SSG output Distortion meter
: –121dBm (0.2µV) (Wide)
: –119dBm (0.25µV) (Narrow)
Mod : 1kHz
Dev : ±3.0kHz (Wide)
Dev : ±1.5kHz (Narrow)
Item
Condition
Test equipment
Terminal
Parts Method
Specifications/
Remarks
Measurement
Adjustment
To Next Page
