TM-271A/E
SPECIFICATIONS
GENERAL
Frequency Range
TX ............................................................................................ K,M4 : 144~148MHz E : 144~146MHz M2,M3 : 136~174MHz
RX ............................................................................................ K,E,M2,M3 : 136~174MHz M4 : 144~148MHz
Mode .......................................................................................... F3E (FM)
Antenna Impedance .................................................................. 50Ω
Usable Temperature Range ...................................................... –20°C~+60°C (–4°F~+140°F)
Power Supply ............................................................................. 13.8V DC± 15% (11.7~15.8V)
Grounding Method .................................................................... Negative ground
Current
Transmit (max.) ...................................................................... K,E,M2,M3 : 13A or less M4 : 8A or less
Receive (at 2W output) ......................................................... 1.0A or less
Frequency Stability (–20°C~+60°C) ......................................... Within ± 2.5ppm
Dimensions (W x H x D projections not included) ..................... 160 x 43 x 137 mm / 6-5/16 x 1-11/16 x 5-13/32 inch
Weight ........................................................................................ Approx. 1.2kg / 2.6lb
RECEIVER
Circuitry ....................................................................................... Double conversion superheterodyne
Intermediate Frequency (1st / 2nd) ............................................ 49.95MHz / 450kHz
Sensitivity (12dB SINAD) ............................................................ Wide : 0.18µV or less Narrow : 0.22µV or less
Selectivity
–6dB ........................................................................................ Wide : 12kHz or more Narrow : 10kHz or more
–60dB ...................................................................................... Wide : 30kHz or less Narrow : 24kHz or less
Squelch Sensitivity ..................................................................... 0.1µV or less
Audio Output (8Ω, 5% distortion) .............................................. 2W or higher (5% distortion)
Audio Output Impedance ........................................................... 8Ω
TRANSMITTER
Power Output
High ......................................................................................... K,E,M2,M3 : 60W M4 : 25W
Low ......................................................................................... K,E,M2,M3 : Approx. 25W
Modulation .................................................................................. Reactance modulation
Spurious Emissions .................................................................... –60dB or less
Maximum Frequency Deviation ................................................. Wide : ± 5kHz Narrow : ± 2.5kHz
Audio Distortion (at 60% modulation) ........................................ 3% or less
Microphone Impedance ............................................................. 600Ω
Note : All specifications (General,
Transmitter and Receiver) are guaran-
teed within the amateur radio band.
Guarantee K,M2,M3,M4 E
frequency range 144~148MHz 144~146MHz
