DE-BA-defsi-0640
69
SYMBOLS:
B
*
= blank or M
B / 0 /.
= blank / weight values / decimal dot, depending on weighing value
g = weight unit / unit / %
E, o, r = ASCII code or “E, o, r”
CR = carriage return symbol
LF = line feed symbol
9.4 Output on bar code printer
The data transfer mode has to be set on „BA Pr“ (chapter 8.5.1).
As bar code printer a Zebra printer model LP2824 is provided.
Take into account that the output format of the balance is fixedly defined and cannot
be changed.
The printer format is stored in the printer, i.e. in case of a failure the printer cannot be
changed with a new one from factory, previously it is necessary that KERN installs
the respective software.
The Zebra printer and the balance must be connected to the delivered interface cable
when they are switched off.
After switching-on both appliances, and after reaching the status ready-for-operation,
a label will be printed out when pressing the key.
