10 EWJ-BA-e-1917
2.2 Overview of display
Zero indicator
The displayed weighing value is a net weighing value
The bar graph display moves from the left to the right
and proceeds equally to the weight loaded onto the
weighing balance. Its full width is reached at maximum
load.
This is an analogue display of the current allocation of
the weighing area.
ο
Stability display
Pcs Indicator for counting
% Indicator for percent determination
Currently selected weight unit
fully loaded
Loading status of the rechargeable battery (prerequisite
menu setting „P9batt on“, see chap. 8.2).
The number of segments informs about the loading
status of the rechargeable battery.
1/2 loaded
empty
