EN
8
For anything not indicated, please refer to paragraph 4.1
DO NOT REMOVE THE REAR COVER!
Fix the bracket to the cross beam (FIG. 26), then connect the steel
rail using one of the two long screws supplied (FIG. 39) and to follow
the instructions of TAB. 1C and TAB. 2.
Raise the rail until parallel to the ground, measure the dimension A
and then cut the two ceiling brackets as shown: dimension A + 3 cm
(FIG. 40). Insert the quick coupling plate, then connect it to the ceil-
ing brackets (FIG. 41, 42).
Fix the brackets to the ceiling using suitable screws and anchors
(not supplied).
Follow the instructions in section 4.1 from FIG. 29 to FIG. 35, by
inserting the arm in the slit of the slider previously cut open with a
utility knife (FIG. 43).
4.2 - 3-part rail assembly
4.3 - Single rail assembly
4.4 - Connection of the motor casing to the steel rails
4.5 - Installation with motor casing on cross beam
4.6 - Standard installation
Assemble the rail (FIG. 4) then pull the belt (FIG. 7)
Pull the belt (FIG. 7)
Follow the instructions in section 4.1 (FIG. 13, 14, 16)
For anything not indicated, please refer to paragraph 4.1
Follow the instructions in section 4.1 from FIG. 25; please be careful
not to connect the bracket to the slot, but to the single hole (FIG. 38)
and to follow the instructions of TAB. 1B and TAB. 2.
Then continue following the instructions in section 4.1
In the event of a power failure and if the optional buer battery is not available, to unlock the automation system:
4.7 - Manual opening of the door
PHASE DESCRIPTION
1 Pull the cord in order to bring the release lever to its vertical position (FIG. 30)
2 Lift or lower the door manually
3 To reset the automation system, move the cord so as to allow the release lever to t fully back into the pulling slider (FIG. 36)
4 Lift or lower the door manually until it engages with the rail
4.8 - Fixing the LED rail opening limit stop
Unlock the slider, manually lift the door until it is in its maximum pos-
sible indicated opening position H - 10 cm (FIG. 44).
Mark the end position of the slider with a pencil (FIG. 45), then drill a
hole and x with the screw (FIG. 46).
4.9 - Fixing the steel rail opening limit stop
Unlock the slider, manually lift the door until it is in its maximum pos-
sible indicated opening position H - 10 cm (FIG. 44).
Firmly fasten the limit stops (FIG. 47).
4.10 - Electrical wiring
Before connecting, check that the control unit is not powered
Follow the connection instructions (FIG. 48)
ATTENTION !
ATTENTION !
ATTENTION !
ATTENTION !
ELECTRICAL WIRING
COM FLASH, LED output common
FLASH Flashing output 24Vdc (not regulated), maximum 3W
LED Courtesy light output 24Vdc (not regulated), maximum 20W
PH-POW Photocell power positive output 24Vdc (not regulated), maximum 100mA
NEG Photocell power negative output
PH Photocells (closing) NC contact between PH and COM
EDGE/EDGE Sensitive edge input, NC contact, 8k2 resistive or 8k2 double resistive (parallel)
