51
1
5
Driving your vehicle
Fuel,
engine coolant and engine
oil
High speed tra
vel consumes more
fuel than urban motoring.
Do not for-
get to check both the engine coolant
and engine oil.
Drive belt
A loose or damaged drive belt ma
y
ov
erheat the engine.
SC PE CAN (ENG) 5.QXP 10/23/2020 7:11 PM Page 115
