Motor
Standard(Ω)
IG series CG series
Part Item Type
120
V
230V/24
0V
120V
230V/240
V
Ignition winding Resistance Green-Yellow/Green 0.40-0.55
Outer charging
winding
Resistance Blue--Blue 0.12-0.15
Sub winding Resistance
White-White (IG)
White-White (CG)
0.15-0.30
Main winding Resistance
Black—Black-Black
(IG)
Black-Yellow/Black-Gr
een/Black-Red
(CG)
1.35-1
.75
5.0-5.5
0.18-0.
21
0.65-0.
90
2.6 Torque values
Tightening torque
Item Specification
N·m kgf·m
Connection rod bolt M5X0.8X25 8-10 0.8-1.0
Spark plug M10X1.0X13 12-15 1.2-1.5
Crankcase cover M6X25 8-10 0.8-1.0
Flywheel nut M12X1.25 70-80 7.0-8.0
M5 Bolt, nut 6-8 0.6-0.8
M6 Blot, nut 8-10 0.8-1.0
Standard torque
M8 Bolt, nut 20-23 2.0-2.3
Note: Use standard torque values for fasteners that are not listed in this table.
2.7 Troubleshooting
a. General symptoms and possible causes
Fuel filter clogged Clean
Fuel tank tube clogged Clean
Fuel switch clogged Clean
Carburetor faulty Readjust and clean
Ignition coil faulty Inspect and replace
Spark plug faulty Inspect and replace
Trigger faulty or trigger clearance
faulty
Inspect and replace
Spark plug cap looses Fix it securely
Low oil alarm faulty Inspect and replace
Ignitor faulty Inspect and replace
Engine does
not start or
hard starting
Ignition winding faulty Inspect and replace
9
