6.7 Flexible coupling details
Sr.
No.
Pump Model Model of Std.
Love-Joy coupling
Model of spacer
type Love-Joy
coupling
* Note: However couplings are selected considering motor kW and motor make.
6.8 Stuffing box
6.8.1 Stuffing box sealing arrangement –
Self liquid sealing is standard supply. External liquid sealing arrangement can be provided on
request.
6.8.2 Stuffing box packing specification – Non Asebetos Graphited cotton greasy packing is used
in the pump as a standard supply. However, stuffing box packing suitable for liquid handled
is supplied against specific requirements.
6.8.3 Stuffing box packing and Lantern ring – Please refer to the following chart for st. box
packing size and position of lantern ring.
Shaft
Unit
St. box packing
size mm (SQ)
Length of
packing mm
Packing arrangement and
Position of Lantern
(L) from impeller side

KIRLOSKAR DB 80/16 Specifications

General

Brand	KIRLOSKAR
Model	DB 80/16
Category	Water Pump
Language	English
