KIRLOSKAR DB 80/16 User Manual

17
This is a proprietary document of Kirloskar Brothers Limited, Kirloskarvadi-416308, Dist-Sangli (India)
ISSUE DATE: 17.09.2010 LAST REV. DATE:
7. SPARE PARTS LIST & CROSS-SECTIONAL DRAWINGS
Part NO. Description Qty. per pump
105 Pump casing central vertical del. end 1
*151 Impeller radial flow, shrouded 1
-180 Pump shaft 1
*190 Casing wear ring, suc. side 1
*190.2 Casing wear ring, del. side 1
220 Casing cover 1
223 Gland 1
*227 Lantern ring 1
*236 Liquid deflector 1
240 Bearing housing 1
251 Support foot 1
*260 Radial ball bearing 2
272 Bearing cover 2
*310 Shaft sleeve 1
*320 Key for impeller 1
321 Key for coupling 1
*330 Impeller nut 1
411 Lock washer for support foot 1
*410 Lock washer for impeller nut 1
*430 Gland packing 4
441 Grease nipple 2
*445 Oil level sight glass (for oil lub. pump) 1
444 Oil filter plug (for lub. pump) 1
*500 Oil seal (for oil lub. pump) 2
*511 Gasket for casing cover 1
*514 Gasket for bearing cover 2
*515 Gasket shaft sleeve 1
631 Hex. screw for cover 6
632 Hex. screw for support foot 1
581 Nut 8/12
582.1 Nut 2
582.2 Nut 6/8
590 Studs for casing 8/12
591.2 Studs for casing cover 2
591.2 Studs for casing cover 6/8
