29
kobalttools.com
CARE AND MAINTENANCE
STAGE 3: Long-Term Storage
Make sure unit is completely clean by following Stages 1 and 2 of the Care and Maintenance section.
For long-term storage of your sprayer, DO NOT leave water in the sprayer system. The use of mineral
1. Make sure safety lock is in locked position, spray valve switch (H) is set to prime position, and the
power switch off.
2. Separate prime tube (C) from suction tube (B) and place prime tube (C) into a waste pail.
3.
4. Turn pressure control knob (F) counterclockwise to lowest setting.
5.
through the sprayer until it comes out of the prime tube (C).
6. Immediately turn power switch off.
7. Unlock safety lock and reconnect prime tube (C) to suction tube (B). Make sure prime tube (C)
8. Point spray gun housing (D) into waste pail and squeeze spray gun housing (D) trigger. Continue
squeezing trigger and turn prime spray valve switch (H) to spray position.
9.
10. , turn power
switch off, and set safety lock to locked position.
Note: Place a plastic bag (not included) over bottom of the suction tube (B) using a
PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION
Motor does not run;
sprayer does not spray.
1. Machine is not plugged in.
2. Power switch is turned off.
3. Control knob is set to low
position.
1. Plug into grounded outlet.
2. Turn power switch on.
3. Turn pressure control knob
clockwise.
Motor is running and
trigger is squeezed,
but spray gun does not
spray.
1. Pressure control knob is set
too low.
1. Turn pressure control knob clockwise
and increase power.
Trigger does not move. 1. Safety trigger is not on. 1. Turn safety lock on spray gun
housing to unlocked position.
If you have any questions regarding the product, please call customer service at
1-888-3KOBALT (1-888-356-2258), 8:00 a.m. - 8:00 p.m., EST, Monday - Friday.
TROUBLESHOOTING
