PM Sheet
M-Series Scrubber PM Sheet
www.timberlineclean.com M-Series PM Sheet RPS Corporation © 2020
CUSTOMER INFORMATION
Customer:
Email:
Address:
Phone:
City:
State:
Zip:
Contact:
MACHINE INFORMATION
Serial #:
Model #:
Work Order #:
NOTE: Start with Machine filled at least with ½ Tank of water. Turn ON Machine and Test Functionality of Machine
CHECK OPERATION & CONDITION OF
IN SPEC
REPAIR
PROBLEM
Key Switch
Battery Gauge
Deck Up / Down – Brush Switch
Brush Pressure +/- Toggle (Optional)
Squeegee Up/Down - Lever
Solution Flow Lever +/-
Green Drive Buttons
Reverse Toggle Switch
E-Stop (Optional)
Spray Jet/Wand
NOTE: Drain Solution & Recovery Tank fully. Rinse out Recovery Tank
CLEAN & INSPECT - TANK
IN SPEC
REPAIR
PROBLEM
Drain / Rinse Recovery Tank
Drain Hose & Plug
Drain / Flush Solution Tank
CLEAN & INSPECT – SOLUTION SYSTEM
IN SPEC
REPAIR
PROBLEM
Solution Fill Screen - Mesh
Solution Fill Hose (Optional)
Solution Filter
Vacuum Muffler Drain Hose
Battery Drain Hose
BRUSH CONDITION – SCRUB DECK
Deck Curtains/Wipers
Good
Worn
Needs Replacement
Brush Sockets: (2-Disk)/(4-Cylindrical)
Good
Worn
Needs Replacement
Brush Drivers: (2-Disk)/(4-Cylindrical)
Good
Worn
Needs Replacement
Scrub Brush Fiber Length
Brush 1 Length:
Brush 2 Length:
Rotated Brushes: Y / N
NOTE: Tip Tank Back
CLEAN & INSPECT – SCRUB DECK
IN SPEC
REPAIR
PROBLEM
Scrub Deck Linkage Pivot Points
Scrub Deck Lift
Scrub Deck Level (Orbital Only)
Pitch of Scrub Deck (Must be level)
Scrub Motor Wires
CLEAN & INSPECT - SQUEEGEE
IN SPEC
REPAIR
PROBLEM
Remove and Wipe off Squeegee
Check and Rotate Blades as Needed
Caster Wheels and Height
Pitch Adjust
Check Pivot and Knobs
Vacuum and Drain Hoses
CLEAN & INSPECT – RECOVERY
IN SPEC
REPAIR
PROBLEM
Vacuum and Drain Hoses
Recovery Tank Lid & Gasket
Vacuum Float Screen
Vacuum Box White Filter
Solution Site Tube
CLEAN & INSPECT - DRIVE
IN SPEC
REPAIR
PROBLEM
Drive Wheels & Casters Condition
Grease Caster Swivel
