TP-6905 9/2148 Section 3 RDC2 Controller Operation
3.18 Programmable Interface
Module (PIM) Menus
The PIM status menu displays the status of inputs and
outputs connected to the programmable interface
module (PIM). This is a status display menu only. Input
and output settings cannot be changed from the RDC2
controller’s user interface.
A personal computer running Kohlerr SiteTecht
software is required to change the input and output
settings. Contact an authorized dealer for service.
The Kohlerr OnCuer Plus Management System can be
used to turn outputs on and off. See the OnCue Plus
Software Operation Manual for instructions.
tp6810
PIM
Status:
PIM 1 - - >
<- - Return
Input 1
In/Active
Output 1:
In/Active
Input 2
In/Active
Output 2:
In/Active
Output 3:
In/Active
Output 4:
In/Active
Output 5:
In/Active
Output 6:
In/Active
<- - Return
Figure 3-22 Programmable Interface Module (PIM) Status Menu
