TP-6772 2/14b22 Section 2 Operation
Generator Metering Menu
Volts displays the alternator output AC voltages. The
display shows all line-to-line and line-to-neutral voltage
combinations for three-phase or single-phase
configurations.
Frequency (Hz) value displays for the output AC
voltage. This value also shows in the Overview Menu.
Reset Calibration provides the means to reset the
configuration values.
The calibration values are reviewable at all times and
provide the calibration of the voltage sensing logic.
Changing the system voltage or replacing the circuit
board requires a calibration adjustment.
To enable calibration
, start the generator set and select
the Volts L1-L2 display. Then push and hold the
pushbutton/rotary selector dial until the Calibration
Enabled popup appears. Calibration of each display is
now available. The display will show the following
values for three-phase generator sets. Single-phase
generator sets will only display items marked (*).
D Volts L1-L2 *
D Volts L2-L3
D Volts L3-L1
D Volts L1-N
D Volts L2-N
D Volts L3-N
The user can change individual values or can select
Reset Calib?--Yes to reset all values. The Reset Calib?
display will only show if calibration is enabled. Refer to
the requirements shown with Generator Set Calibration
in 2.7.7 Status and Notice Digital Displays.
To disable calibration
, Rotate the pushbutton/rotary
selector dial until the <--Return popup appears.
Momentarily press the pushbutton/rotary selector dial.
Stop the generator set if not already done.
Generator Set Information Menu
GenSet M/N displays the generator set model number.
GenSet S/N displays the generator set serial number.
Controller S/N displays the controller serial number.
Generator Set Run Time Menu
Engine Run Time displays the total run time hours.
This value also shows in the Overview Menu.
Engine Starts displays the total number of generator
set startup events.
Next Maintenance displays the next maintenance
timer. The maintenance interval for the ADC IId is
250 hours.
Generator Set System Menu
The values in these menus are user-entered for the
generator set configuration and are NOT measured
values of the generator set.
System Frequency displays the programmer-entered
L1/L2/L3 output voltage frequency for three-phase o r
the L1/L2 output voltage frequency for single-phase.
Battery Voltage displays the engine electrical system
12 or 24 volts.
CAN A displays the remote communication’s protocol in
use (J1939, SmartCraft, or NMEA 2000).
Note: After changing the CAN A communication setting,
power off and then power on the controller.
Measure Units displays the user selected unit of
measure as Metric or English.
Contrast displays user selected resolution values to
improve digital display clarity.
Voltage Regulator Menu
The voltage regulator value is reviewable at all times
and provides the ability to fine adjust voltage. Changing
the system voltage or replacing the circuit board
typically requires a voltage adjustment.
To enable calibration
, start the generator set and select
the VR Volt Adj, Volt/Hz, Gain, or Stabil display. Then
push and hold the pushbutton/rotary selector dial until
the Editing Enabled popup appears. Editing of the
Voltage Adjustment, Volts/Hz, Gain, and Stability is now
available.
The user can change the individual value or can select
Reset VR?--Yes to reset to the default value. The Reset
VR Settings display will only show if editing is enabled.
To disable calibration
, r otate the pushbutton/rotary
selector dial until the <--Return popup appears.
Momentarily press the pushbutton/rotary selector dial.
Stop the generator set if not already done.
