- 20 -
DISASSEMBLY/REASSEMBLY
WARNINGS!
During repair operations, when
using compressed air, wear eye
protection.
DISASSEMBLY AND REASSEMBLY
Besides disassembly and reassembly operations this chapter also
includes checking and setting specications, dimensions, repair and
operating instructions.Always use original KOHLER spare parts for
repairoperations.

Clean the ltering element with air blast. Air must be blown
frominsidetooutsidethecartridgeatadistanceofatleast15
cmfromthepaper.
Lightly and repeatedly tap the element on a hard surface to
eliminateallexcessdirt.
Cartridgecomponents:
 
1Seal
2 Metallicbody
3 Polyurethaneprelter
4 outermesh  
5Filtermedia
6 Blade
7 Insideenvelope
8 Metallicbody
9Innerseal
Cartridge characteristics:
mediaporosity7µm,usefullteringarea1960cm
2
.
Polyurethane pre-lter characteristic:
porosity60p.p.i.,frontarea207cm
2
.
Note: Pre-lter3canundergomaintenanceoperations;ifdirty,wash
withsoapand water and dry(maximum10 cleanings ).See
page18forcartridgereplacement.
Clean the ltering element with air blast. Air must be blown
frominsidetooutsidethecartridgeatadistanceofatleast15
cmfromthepaper.
Lightly and repeatedly tap the element on a hard surface to
eliminateallexcessdirt.Replaceifirreparablyclogged.
Cartridgecomponents:
1 Completecover
2Filteringmaterial
3Support
Characteristicsofthelteringmaterial:
paperporosity:3µm
lteringarea:4400cm²
outerringinopen-cellpolyurethane
Seepage18forthefrequencywithwhichthelteringmaterialmust
bechanged.
KD 225_315_350_400_440 Workshop Manual_cod. ED0053029330_1° ed_ rev.00
Dry air cleaner for KD 315 and KD 350
Dry air cleaner for KD 225
