Kohler KPC 1000 User Manual

TT-1625 7/17 45
Parts List
Remote Serial Annunciator Kits and Communication Module Kit
Qty. Description
Remote Serial Annunciator Kits GM91356
Standard RSA Kits
Decision-Makerr 3+ RSA Kits
with communication module
KPC 1000 RSA Kits
-KP1,
-S1:
No ATS
-KP2,
-S2:
One ATS
-KP3,
-S3:
Four ATS
-S4:
No ATS
-S5:
One ATS
-S6:
Four ATS
-S7:
No ATS
-S8:
One ATS
-S9:
Four ATS
1 Ribbon cable,
10-position
GM21340 GM21340 GM21340
1 Ribbon cable,
24-position
GM32632 GM32632 GM32632
3 Spacer, 8-32 x 5/8
male-female
GM32633 GM32633 GM32633
1 Communication
module board
GM49791-1 GM49791-1 GM49791-1
1 Harness, comm. HBV
wiring
GM35318 GM35318 GM35318
1 Remote serial
annunciator overlay
GM85132 GM85131 GM85127 GM85132 GM85131 GM85127 GM85132 GM85131 GM85127
5 Screw, plastic
self-tapping
GM23307 GM23307 GM23307 GM23307 GM23307 GM23307 GM23307 GM23307 GM23307
1 Board, main logic
GM86125 GM86125 GM86125 GM86125 GM86125 GM86125 GM86125 GM86125 GM86125
2 Euroblock plug,
6-position
GM62619 GM62619 GM62619 GM62619 GM62619 GM62619 GM62619 GM62619 GM62619
1 Euroblock plug,
8-position
GM62699 GM62699 GM62699 GM62699 GM62699 GM62699 GM62699 GM62699 GM62699
1 Bezel
GM85134 GM85134 GM85134 GM85134 GM85134 GM85134 GM85134 GM85134 GM85134
1 Box, RSA III
GM85125 GM85125 GM85125 GM85125 GM85125 GM85125 GM85125 GM85125 GM85125
1 Connector plug,
6-position
337131 337131 337131
4 Screw, self-tapping
X-6071-7 X-6071-7 X-6071-7 X-6071-7 X-6071-7 X-6071-7 X-6071-7 X-6071-7 X-6071-7
3 Washer, #8 lock
X-22-7 X-22-7 X-22-7
1 Harness, pigtail
GM60452 GM60452 GM60452
1 Connector plug,
15-position
30712 30712 30712
1 Plate, wall-mounting
GM85126 GM85126 GM85126 GM85126 GM85126 GM85126 GM85126 GM85126 GM85126
Communication Module Kit
Qty. Description GM32644-KP1
1 Ribbon cable, 10-position GM21340
1 Communication module board GM49791-1
1 Ribbon cable, 24-position GM32632
3 Spacer, 8-32 x 5/8 male-female GM32633
3 Washer, #8 l ock X-22-7
1 Harness, communication HBV wiring GM35318
AC Adapter Kit
Qty. Description GM62466-KP1
1 Clamp, power supply GM60404
1 Supply, power GM60407
1 Screw, hex X-67-113
1 Block, terminal GM20930
1 Gasket, rubber —
