2.
Turn the key of starting switch (1) to OFF position (A), and
stop the engine.
3.
Remove the key from starting switch (1).
REMARK
• After the engine is stopped, DEF in DEF injector and
pump is automatically purged and returned to the tank
to prevent malfunction of the devices caused by freez-
ing of DEF or deposition of urea.
For this purpose, the devices keep operating for sev-
eral minutes after starting switch (1) is turned to OFF
position, and this does not indicate abnormality.
In addition, the system operating lamp lights up while
devices are operating to purge DEF to the tank. Do
not turn the battery disconnect switch to OFF position
while the system operating lamp is lit. After DEF has
been purged completely, the devices stop automatical-
ly.
• If the starting switch (1) key is turned to OFF position
(A) while the engine is still hot, guidance (2) may be
displayed on the machine monitor. To cool down the
engine before stopping, run it at low idle the next time
and after, because it may cause damage to the devi-
ces.
METHOD FOR STARTING MACHINE (TRAVEL FORWARD AND REVERSE,
AND SHIFTING GEAR) AND STOPPING MACHINE
METHOD FOR MOVING MACHINE
kk
WARNING
• Always disengage the frame lock bar during traveling. If it is not disengaged, the steering becomes
inoperative and this may lead to serious personal injury or death.
• Before moving the machine off, check that the area around the machine is safe, then sound the
horn before starting.
• Do not allow anyone to enter the area around the machine.
• Clear any obstacles from the travel path.
• There is a blind spot behind the machine, so be extremely careful when driving the machine in re-
verse.
• Do not try to make directional change abruptly while the engine speed is high.
MACHINE OPERATIONS AND CONTROLS OPERATION
3-182
