4. Press an input button (either IN 1 or IN 2) once
1
5. Enter the One output mode as defined in
.
The selected input button illuminates.
Table 2 (with either IN 1 or
IN 2).
6. Press that input button to set the appropriate OUTPUT STATUS LED.
The OUTPUT STATUS LED blinks indicating that that output channel is
selected.
7. Press the LOCK button to copy the EDID of the selected OUTPUT to the
input.
Note: to cancel the EDID modification, press the EDID button before
pressing the LOCK button.
While the EDID is being copied the EDID button blinks. The new EDID
is copied, when the EDID button no longer blinks.
6.4.2 Acquiring the Default EDID
To reset the default EDID, do the following:
1. Connect the power supply.
2. Press the EDID button for more than 3 seconds.
3. Press an input button (either IN 1 or IN 2)
1
once.
The selected input button illuminates.
4. Enter the default mode as defined in
Table 2 (with either IN 1 or IN 2).
All the OUTPUT STATUS LEDs blink simultaneously.
5. Press the LOCK button to copy the default EDID to the input.
Note: to cancel the EDID modification, press the EDID button before
pressing the LOCK button.
While the EDID is being copied the EDID button blinks. The new EDID
is copied, when the EDID button no longer blinks.
6.4.3 Acquiring the EDID from several Outputs
To acquire or change an EDID via several connected outputs:
1. Connect the power supply.
2. Connect several output display devices.
3. Press the EDID button for more than 3 seconds.
4. Press an input button (either IN 1 or IN 2)
1
once.
The selected input button illuminates.
1 Depending if you want to copy the new EDID to input 1 or to input 2
