4 TECHNICAL DATA - TIGHTENING TORQUES FOR CHASSIS 11

Screw, combination switch, left M4 2 Nm (1.5 lbf ft) –

Screw, side stand switch M4 2 Nm (1.5 lbf ft) –

Remaining screws, chassis M5 5 Nm (3.7 lbf ft) –

Screw, brake line holder on swingarm M5 5 Nm (3.7 lbf ft) –

Screw, cable channel M5 5 Nm (3.7 lbf ft) –

Screw, cable guide, wheel speed sen-

sor, rear

M5 3 Nm (2.2 lbf ft) –

Screw, chain sliding guard M5 5 Nm (3.7 lbf ft) –

Screw, combination switch, right M5 3.5 Nm (2.58 lbf ft) –

Screw, cover part M5x12 3.5 Nm (2.58 lbf ft) –

Screw, filler cap M5 3 Nm (2.2 lbf ft) –

Screw, foot brake lever stub M5 6 Nm (4.4 lbf ft) Loctite

243™

Screw, fuel level indicator M5 3 Nm (2.2 lbf ft) –

Screw, heat guard on main silencer M5 4 Nm (3 lbf ft) –

Screw, wind shield M5 3.5 Nm (2.58 lbf ft) –

Spoke nipple M5 4… 6 Nm (3… 4.4 lbf ft) –

Ground fitting on frame M6 6 Nm (4.4 lbf ft) –

Nut, ABS unit fixation M6 8 Nm (5.9 lbf ft) –

Remaining chassis nuts M6 10 Nm (7.4 lbf ft) –

Remaining chassis screws M6 10 Nm (7.4 lbf ft) –

Screw, ball joint of push rod on foot

brake cylinder

M6 10 Nm (7.4 lbf ft) Loctite

243™

Screw, battery terminal M6 4.5 Nm (3.32 lbf ft) –

Screw, brake line holder on bottom

triple clamp

M6 10 Nm (7.4 lbf ft) –

Screw, cable channel M6 5 Nm (3.7 lbf ft) –

Screw, chain guide M6 5 Nm (3.7 lbf ft) Loctite

243™

Screw, clutch assembly M6 5 Nm (3.7 lbf ft) –

Screw, cooler retaining bracket M6 7 Nm (5.2 lbf ft) –

Screw, cover part M6 6 Nm (4.4 lbf ft) –

Screw, engine guard M6 10 Nm (7.4 lbf ft) –

Screw, exhaust clamp M6 8 Nm (5.9 lbf ft) –

Screw, foot brake cylinder M6 10 Nm (7.4 lbf ft) Loctite

243™

Screw, front brake disc M6 14 Nm (10.3 lbf ft) Loctite

243™

Screw, fuel pump M6 6 Nm (4.4 lbf ft) –

Screw, fuel tank M6 10 Nm (7.4 lbf ft) –

Screw, fuel tap M6 6 Nm (4.4 lbf ft) –

Screw, lower rear part M6 6 Nm (4.4 lbf ft) –

Screw, magnetic holder on side stand M6 6 Nm (4.4 lbf ft) Loctite

243™

Screw, rear brake disc M6 14 Nm (10.3 lbf ft) Loctite

243™

Screw, voltage regulator M6 6 Nm (4.4 lbf ft) –

Screw, wheel speed sensor, front M6 10 Nm (7.4 lbf ft) –

Screw, wheel speed sensor, rear M6 10 Nm (7.4 lbf ft) –

Remaining chassis nuts M8 25 Nm (18.4 lbf ft) –

Remaining chassis screws M8 25 Nm (18.4 lbf ft) –

Screw, bottom triple clamp M8 12 Nm (8.9 lbf ft) –

Screw, foot brake lever M8 25 Nm (18.4 lbf ft) Loctite

243™

Screw, fork stub M8 15 Nm (11.1 lbf ft) –

Screw, front footrest bracket M8 25 Nm (18.4 lbf ft) Loctite

243™

Screw, handlebar clamp M8 20 Nm (14.8 lbf ft) –

Screw, ignition lock (tamper-proof

screw)

M8 25 Nm (18.4 lbf ft) Loctite

243™

Screw, manifold holder M8 45 Nm (33.2 lbf ft) Loctite

243™

Questions and Answers:

Need help?

Do you have a question about the KTM 1190 Adventure 2014 and is the answer not in the manual?

KTM 1190 Adventure 2014 Specifications

General

Displacement	1195 cc
Bore x Stroke	105 mm x 69 mm
Torque	125 Nm @ 7500 rpm
Compression Ratio	12.5:1
Starter	Electric starter
Transmission	6-speed
Fuel System	Electronic fuel injection
Cooling	Liquid cooled
Frame	Chromium-Molybdenum steel trellis frame, powder coated
Front Suspension	WP USD Ø 48 mm
Suspension Travel Front	190 mm
Suspension Travel Rear	190 mm
Wheelbase	1560 mm
Ground Clearance	220 mm
Fuel Tank Capacity	23 liters
Dry Weight	217 kg
Engine Type	2-cylinder, 4-stroke, V 75-degree
Power	110 kW (150 hp) @ 9500 rpm
Clutch	hydraulically actuated
Rear Suspension	WP monoshock
Front Brake	Twin disc brake, diameter 320 mm
Rear Brake	Disc brake, diameter 267 mm
ABS	Bosch 9ME Combined-ABS
Seat Height	860 mm
