MAINTENANCE WORK ON CHASSIS AND ENGINE 100
700347-01
– Turn adjusting screws clockwise until they stop.
Info
The adjusting screws are located at the top end of the fork legs.
Make the same adjustment on both fork legs.
– Turn back counterclockwise by the number of clicks corresponding to the fork type.
Guideline
Rebound damping
Comfort 15 clicks
Standard 10 clicks
Sport 5 clicks
Full payload 5 clicks
Info
Turn clockwise to increase damping, turn counterclockwise to reduce suspension
damping.
9.8Adjusting the spring preload of the fork
Info
The spring preload defines the initial situation of the spring process of the fork.
An optimally adjusted spring preload is adapted to the rider's weight and ensures a compromise between easy handling and stabil-
ity.
