MAINTENANCE WORK ON CHASSIS AND ENGINE 115
700308-01
– Position the footrest bracket with spacers  and screws.
Guideline
Standard Lower position
Info
The adjustable footrest bracket enables a more comfortable lower footrest posi-
tion or a sporting upper footrest position.
700306-01
– Mount and tighten screws.
Guideline
Screw, front footrest bracket M8 25 Nm
(18.4 lbf ft)
Loctite
®
243™
700309-01
– Repeat adjustment work on the footrest bracket on the other side.
– Adjust the shift lever. ( p. 116)
– Adjust the footbrake pedal. ( p. 121)

KTM 1190 RC8 Specifications

General

Engine Type	V-Twin, 4-stroke
Displacement	1195 cc
Transmission	6-speed
Cooling	Liquid cooled
Fuel Tank Capacity	16.5 liters
Rear Brakes	Single 220 mm disc, Brembo 2-piston caliper
Seat Height	805 mm
Front Suspension	WP USD Ø 43 mm
Rear Suspension	WP monoshock
Front Brakes	2 x 320 mm discs, radially mounted Brembo 4-piston calipers
Frame	Chromium-Molybdenum tubular space frame, powder-coated
