16 TUNING THE ENGINE 151
» If the clutch lever play changes:
– Check the routing of the clutch cable.
16.4 Adjusting the clutch cable play
S00683-10
– Move the handlebar to the straight-ahead position.
–
Push back sleeve

.
–
Loosen lock nut

.
–
Adjust the play in the clutch level

by turning adjusting screw

.
Guideline
Clutch lever play 1… 3 mm (0.04… 0.12 in)
–
Tighten lock nut

.
–
Position bellows

.

KTM 125 Duke Specifications

General

Displacement	124.7 cc
Max Power	14.5 hp @ 9, 250 rpm
Max Torque	12 Nm @ 8, 000 rpm
Transmission	6-speed
Front Suspension	WP APEX 43
Rear Suspension	WP APEX Monoshock
Fuel Tank Capacity	13.4 liters
Seat Height	830 mm
Bore x Stroke	58 mm x 47.2 mm
Compression Ratio	12.8:1
Ground Clearance	175 mm
Wheelbase	1, 357 mm
Front Tyre	110/70 R17
Rear Tyre	150/60 R17
Fuel System	Electronic Fuel Injection (EFI)
Rear Brake	230 mm disc
Frame	Steel trellis frame, powder-coated
Engine Type	Single Cylinder, 4 Stroke, Liquid Cooled, DOHC
