TECHNICAL DATA 20
123
IJ Idling jet
NDL Needle
POS Needle position from top
MJ Main jet
Info
Do not use on sandy terrain.
20.3.6 Basic carburetor setting for sandy surfaces (All 150 models)
Idle air adjusting screw
Open 2 turns
Idling jet 37.5
Jet needle 6BFY42‑71
Needle position 3rd position from top
Main jet 540
Info
If the engine is not running smoothly, use a smaller main jet.
20.4 Capacities
20.4.1 Gear oil
Gear oil 0.80 l (0.85 qt.) Engine oil (15W/50) ( p. 129)
20.4.2 Coolant
Coolant 1.2 l (1.3 qt.) Coolant ( p. 129)
20.4.3 Fuel
Total fuel tank capacity, approx. 7.5 l (1.98 US gal) Super unleaded (98 octane) mixed
with 2-stroke engine oil (1:40)
( p. 130)
20.5 Chassis
Frame Central tube frame made of chrome molybdenum steel
tubing
Fork WP Suspension Upside down AER 48
Suspension travel
front 310 mm (12.2 in)
rear 300 mm (11.81 in)
Fork offset 22 mm (0.87 in)
Shock absorber WP Suspension 5018 DCC Link
Brake system Disc brakes, brake calipers on floating bearings
Brake discs - diameter
front 260 mm (10.24 in)
