23 TECHNICAL DATA 174

Screw, water pump wheel M6 10 Nm (7.4 lbf ft) Loctite

243™

Stud, chain shaft M6 8 Nm (5.9 lbf ft) –

Vacuum connection M6 2.5 Nm (1.84 lbf ft) Loctite

243™

Nozzle 100 M6x0.75 4 Nm (3 lbf ft) Loctite

243™

Oil nozzle M6x0.75 4 Nm (3 lbf ft) Loctite

243™

Plug, crankshaft retainer M8 15 Nm (11.1 lbf ft) –

Screw, camshaft bearing support M8 – 10.9 Step 1

10 Nm (7.4 lbf ft)

Step 2

18 Nm (13.3 lbf ft)

–

Screw, engine case M8 18 Nm (13.3 lbf ft) –

Screw, engine console M8 20 Nm (14.8 lbf ft) Loctite

243™

Screw, timing chain guide rail M8 15 Nm (11.1 lbf ft) Loctite

243™

Screw, timing chain tensioning rail M8 15 Nm (11.1 lbf ft) Loctite

243™

Stud, exhaust flange M8 10 Nm (7.4 lbf ft) –

Oil pressure sensor M10x1 10 Nm (7.4 lbf ft) –

Plug, cam lever axis M10x1 15 Nm (11.1 lbf ft) –

Plug, clutch lubrication M10x1 10 Nm (7.4 lbf ft) –

Screw, conrod bearing M10x1 Step 1

25 Nm (18.4 lbf ft)

Step 2

30 Nm (22.1 lbf ft)

Step 3

90°

–

Screw, timing chain tensioner release M10x1 10 Nm (7.4 lbf ft) –

Spark plug M10x1 15 Nm (11.1 lbf ft) –
