BRAKE SYSTEM 13
135
H01142-10
–
Position the screw cap lock and mount and tighten screw
1
.
Guideline
Screw, compensating
tank cap lock, rear
brake
M5 9 Nm (6.6 lbf ft)
13.8 Checking the rear brake linings
Warning
Danger of accidents Worn-out brake linings reduce the braking effect.
– Ensure that worn-out brake linings are replaced immediately. (Your authorized KTM workshop will be
glad to help.)
Warning
Danger of accidents Damaged brake discs reduce the braking effect.
If the brake linings are not changed in time, the brake lining carriers grind against the brake disc. As a
consequence, the braking effect is greatly reduced and the brake discs are destroyed.
– Check the brake linings regularly.
